Spindellager

Das Bild kann vom Produkt abweichen. Weitere Informationen finden Sie in den technischen Daten.

Spindellager

Spindellager sind kritische Komponenten in Werkzeugmaschinen, Industrierobotern und schnell rotierenden Anlagen, die in erster Linie zur Lagerung und Führung der Spindelrotation dienen. Zu den gängigen Typen zählen Schrägkugellager, Zylinderrollenlager und Hybridkeramiklager, die sich durch hohe Präzision, hohe Steifigkeit und geringe Reibung auszeichnen. Sie erfüllen die Anforderungen an hohe Drehzahlen, hohe Belastungen und hervorragende Stabilität und spielen eine entscheidende Rolle in der Präzisionsbearbeitung, Luft- und Raumfahrt sowie in der Automatisierungsindustrie.

Standard

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh,DIN / VDEh

Innenringdurchmesser

10mm-280mm

Außenringdurchmesser

20mm-400mm

Gewicht

0.2kg-300kg

Material

GCr15, 52100, 100Cr6, SUJ2, Edelstahl, deutscher hochstickstoffhaltiger Edelstahl CRONIDUR30, Keramik

Marke

QIBR/OEM/Neutral

Anwendungen

Werkzeugmaschinenspindel, Zentrifuge, Druckerhöhungspumpe, Ölpumpe, Gebläse, verschiedene Getriebe, Laborgeräte

Verpackung

QIBR/Standard-Industrieverpackung/OEM

Paarungsmethode

DB, DF, DT, DBD, DBB, SU

Spindellager

Filter

Nr. Produkt Produktnummer Dynamische Tragzahl Statische Tragzahl Innendurchmesser (d) Masse Außendurchmesser (D) Breite (B)
6301 XC707-C-P2-DB-M/ XC707-C-P2-DB-M 4.05 KN 0.8 KN 7 mm 0.007 kg 19 mm 6 mm
6302 XCB707-C-P2-DT/ XCB707-C-P2-DT 4.05 KN 0.8 KN 7 mm 0.007 kg 19 mm 6 mm
6303 XCB707-E-P2-DT-M/ XCB707-E-P2-DT-M 4.05 KN 0.8 KN 7 mm 0.007 kg 19 mm 6 mm
6304 XC707-C-P2-DT/ XC707-C-P2-DT 4.05 KN 0.8 KN 7 mm 0.007 kg 19 mm 6 mm
6305 XC707-E-P2-DT-M/ XC707-E-P2-DT-M 4.05 KN 0.8 KN 7 mm 0.007 kg 19 mm 6 mm
6306 XC707-C-P2-H/ XC707-C-P2-H 4.05 KN 0.8 KN 7 mm 0.007 kg 19 mm 6 mm
6307 XCB707-C-P2-DB-M/ XCB707-C-P2-DB-M 4.05 KN 0.8 KN 7 mm 0.007 kg 19 mm 6 mm
6308 XC707-C-T-P4S/ XC707-C-T-P4S 4.05 KN 0.8 KN 7 mm 0.007 kg 19 mm 6 mm
6309 XC707-E-T-P4S/ XC707-E-T-P4S 4.05 KN 0.8 KN 7 mm 0.007 kg 19 mm 6 mm
6310 XC707-CDLR-T-P4S/ XC707-CDLR-T-P4S 4.05 KN 0.8 KN 7 mm 0.007 kg 19 mm 6 mm
6311 XC707-EDLR-T-P4S/ XC707-EDLR-T-P4S 4.05 KN 0.8 KN 7 mm 0.007 kg 19 mm 6 mm
6312 XC707-E-P4S-DF/ XC707-E-P4S-DF 4.05 KN 0.8 KN 7 mm 0.007 kg 19 mm 6 mm
6313 XC707-C-P4S-DF/ XC707-C-P4S-DF 4.05 KN 0.8 KN 7 mm 0.007 kg 19 mm 6 mm
6314 XC707-EDLR-TX-P2/ XC707-EDLR-TX-P2 4.05 KN 0.8 KN 7 mm 0.007 kg 19 mm 6 mm
6315 XC707-CDLR-TX-P2/ XC707-CDLR-TX-P2 4.05 KN 0.8 KN 7 mm 0.007 kg 19 mm 6 mm
6316 XC707-C-P4S-U/ XC707-C-P4S-U 4.05 KN 0.8 KN 7 mm 0.007 kg 19 mm 6 mm
6317 XC707-E-P4S-U/ XC707-E-P4S-U 4.05 KN 0.8 KN 7 mm 0.007 kg 19 mm 6 mm
6318 XC707-E-P4S-DB/ XC707-E-P4S-DB 4.05 KN 0.8 KN 7 mm 0.007 kg 19 mm 6 mm
6319 XC707-C-P4S-DB/ XC707-C-P4S-DB 4.05 KN 0.8 KN 7 mm 0.007 kg 19 mm 6 mm
6320 XCB707-E-P2-DB/ XCB707-E-P2-DB 3.90 KN 0.77 KN 7 mm 0.007 kg 19 mm 6 mm
6321 XCB707-E-T-P4S/ XCB707-E-T-P4S 3.90 KN 0.77 KN 7 mm 0.007 kg 19 mm 6 mm
6322 XCB707-C-T-P4S/ XCB707-C-T-P4S 4.05 KN 0.80 KN 7 mm 0.007 kg 19 mm 6 mm
6323 XCB707-CDLR-T-P4S/ XCB707-CDLR-T-P4S 4.05 KN 0.80 KN 7 mm 0.007 kg 19 mm 6 mm
6324 XCB707-EDLR-T-P4S/ XCB707-EDLR-T-P4S 3.90 KN 0.77 KN 7 mm 0.007 kg 19 mm 6 mm
6325 XCB707-C-P4S-U/ XCB707-C-P4S-U 4.05 KN 0.80 KN 7 mm 0.007 kg 19 mm 6 mm
6326 XCB707-E-P4S-U/ XCB707-E-P4S-U 3.90 KN 0.77 KN 7 mm 0.007 kg 19 mm 6 mm
6327 XCB707-E-P4S-DF/ XCB707-E-P4S-DF 4.05 KN 0.80 KN 7 mm 0.007 kg 19 mm 6 mm
6328 XCB707-C-P4S-DB/ XCB707-C-P4S-DB 4.05 KN 0.80 KN 7 mm 0.007 kg 19 mm 6 mm
6329 XCB707-C-P4S-DF/ XCB707-C-P4S-DF 4.05 KN 0.80 KN 7 mm 0.007 kg 19 mm 6 mm
6330 XCB707-E-P4S-DB/ XCB707-E-P4S-DB 3.90 KN 0.77 KN 7 mm 0.007 kg 19 mm 6 mm
6331 HS707-C-P2-DB-H/ HS707-C-P2-DB-H 1.70 KN 0.8 KN 7 mm 0.010 kg 19 mm 6 mm
6332 HS707-E-T-P4S/ HS707-E-T-P4S 1.70 KN 0.8 KN 7 mm 0.010 kg 19 mm 6 mm
6333 HS707-C-T-P4S/ HS707-C-T-P4S 1.70 KN 0.8 KN 7 mm 0.010 kg 19 mm 6 mm
6334 HS707-EDLR-T-P4S/ HS707-EDLR-T-P4S 1.70 KN 0.8 KN 7 mm 0.010 kg 19 mm 6 mm
6335 HS707-C-DLR-T-P4S/ HS707-C-DLR-T-P4S 1.70 KN 0.8 KN 7 mm 0.010 kg 19 mm 6 mm
6336 HS707-C-P4S-U/ HS707-C-P4S-U 1.70 KN 0.8 KN 7 mm 0.010 kg 19 mm 6 mm
6337 HS707-E-P4S-U/ HS707-E-P4S-U 1.70 KN 0.8 KN 7 mm 0.010 kg 19 mm 6 mm
6338 HS707-C-P4S-DB/ HS707-C-P4S-DB 1.70 KN 0.8 KN 7 mm 0.010 kg 19 mm 6 mm
6339 HS707-C-T-P4S-DF/ HS707-C-T-P4S-DF 1.70 KN 0.8 KN 7 mm 0.010 kg 19 mm 6 mm
6340 HS707-E-T-P4S-DF/ HS707-E-T-P4S-DF 1.70 KN 0.8 KN 7 mm 0.010 kg 19 mm 6 mm
6341 HS707-E-P4S-DB/ HS707-E-P4S-DB 1.70 KN 0.8 KN 7 mm 0.010 kg 19 mm 6 mm
6342 7900CLP2/ 7900CLP2 3150 N 1520 N 10 mm 90 g 22 mm 6 mm
6343 7900CL/ 7900CL 3150 N 1520 N 10 mm 90 g 22 mm 6 mm
6344 7900CTYN/ 7900CTYN 3150 N 1520 N 10 mm 90 g 22 mm 6 mm
6345 7000CLP2/ 7000CLP2 5500 N 2490 N 10 mm 19 g 26 mm 8 mm
6346 7000CL/ 7000CL 5500 N 2490 N 10 mm 19 g 26 mm 8 mm
6347 7956A5TYNDBLP4/ 7956A5TYNDBLP4 256 KN 390 KN 280 mm 12.953 kg 380 mm 46 mm
6348 7928A5TYNDBLP4/ 7928A5TYNDBLP4 75.0 KN 90.0 KN 140 mm 1.630 kg 190 mm 24 mm
6349 7921A5TYNDBLP4/ 7921A5TYNDBLP4 48.0 KN 54.0 KN 105 mm 0.820 kg 145 mm 20 mm
6350 7921A5TYNDBLP4/ 7921A5TYNDBLP4 48.0 KN 54.0 KN 105 mm 0.820 kg 145 mm 20 mm
6351 7926A5TYNDBLP4/ 7926A5TYNDBLP4 74.0 KN 88.0 KN 130 mm 1.540 kg 180 mm 24 mm
6352 7924A5TYNDBLP4/ 7924A5TYNDBLP4 67.5 KN 77.0 KN 120 mm 1.150 kg 165 mm 22 mm
6353 7930A5TYNDBLP4/ 7930A5TYNDBLP4 96.5 KN 115 KN 150 mm 2.970 kg 210 mm 28 mm
6354 7934A5TYNDBLP4/ 7934A5TYNDBLP4 106 KN 140 KN 170 mm 3.360 kg 230 mm 28 mm
6355 7936A5TYNDBLP4/ 7936A5TYNDBLP4 137 KN 174 KN 180 mm 4.940 kg 250 mm 33 mm
6356 7932A5TYNDBLP4/ 7932A5TYNDBLP4 100 KN 125 KN 160 mm 3.120 kg 220 mm 28 mm
6357 7938A5TYNDBLP4/ 7938A5TYNDBLP4 139 KN 182 KN 190 mm 5.120 kg 260 mm 33 mm
6358 7952A5TYNDBLP4/ 7952A5TYNDBLP4 241 KN 345 KN 260 mm 11.936 kg 360 mm 46 mm
6359 7948A5TYNDBLP4/ 7948A5TYNDBLP4 189 KN 270 KN 240 mm 7.224 kg 320 mm 38 mm
6360 7944A5TYNDBLP4/ 7944A5TYNDBLP4 179 KN 242 KN 220 mm 6.665 kg 300 mm 38 mm
6361 7940A5TYNDBLP4/ 7940A5TYNDBLP4 178 KN 231 KN 200 mm 6.920 kg 280 mm 38 mm
6362 7920A5TYNDBLP4/ 7920A5TYNDBLP4 47.5 KN 51.5 KN 100 mm 0.808 kg 140 mm 20 mm
6363 7922A5TYNDBLP4/ 7922A5TYNDBLP4 49.0 KN 56.0 KN 110 mm 0.877 kg 150 mm 20 mm
6364 7918A5TYNDBLP4/ 7918A5TYNDBLP4 39.5 KN 43.5 KN 90 mm 0.560 kg 125 mm 18 mm
6365 7919A5TYNDBLP4/ 7919A5TYNDBLP4 40.0 KN 45.5 KN 95 mm 0.603 kg 130 mm 18 mm
6366 7919A5DB/ 7919A5DB 40.0 KN 45.5 KN 95 mm 0.603 kg 130 mm 18 mm
6367 7921A5DB/ 7921A5DB 48.0 KN 54.0 KN 105 mm 0.820 kg 145 mm 20 mm
6368 7918A5DB/ 7918A5DB 39.5 KN 43.5 KN 90 mm 0.560 kg 125 mm 18 mm
6369 7920A5DB/ 7920A5DB 47.5 KN 51.5 KN 100 mm 0.808 kg 140 mm 20 mm
6370 7934A5DB/ 7934A5DB 106 KN 140 KN 170 mm 3.360 kg 230 mm 28 mm
6371 7938A5DB/ 7938A5DB 139 KN 182 KN 190 mm 5.120 kg 260 mm 33 mm
6372 7936A5DB/ 7936A5DB 137 KN 174 KN 180 mm 4.940 kg 250 mm 33 mm
6373 7928A5DB/ 7928A5DB 75.0 KN 90.0 KN 140 mm 1.630 kg 190 mm 24 mm
6374 7932A5DB/ 7932A5DB 100 KN 125 KN 160 mm 3.120 kg 220 mm 28 mm
6375 7924A5DB/ 7924A5DB 67.5 KN 77.0 KN 120 mm 1.150 kg 165 mm 22 mm
6376 7922A5DB/ 7922A5DB 49.0 KN 56.0 KN 110 mm 0.877 kg 150 mm 20 mm
6377 7930A5DB/ 7930A5DB 96.5 KN 115 KN 150 mm 2.970 kg 210 mm 28 mm
6378 7926A5DB/ 7926A5DB 74.0 KN 88.0 KN 130 mm 1.540 kg 180 mm 24 mm
6379 7944A5DB/ 7944A5DB 179 KN 242 KN 220 mm 6.665 kg 300 mm 38 mm
6380 7940A5DB/ 7940A5DB 178 KN 231 KN 200 mm 6.920 kg 280 mm 38 mm
6381 7952A5DB/ 7952A5DB 241 KN 345 KN 260 mm 11.936 kg 360 mm 46 mm
6382 7948A5DB/ 7948A5DB 189 KN 270 KN 240 mm 7.224 kg 320 mm 38 mm
6383 7956A5DB/ 7956A5DB 256 KN 390 KN 280 mm 12.953 kg 380 mm 46 mm
6384 7918A5TR/P4Y/ 7918A5TR/P4Y 39.5 KN 43.5 KN 90 mm 0.560 kg 125 mm 18 mm
6385 7922A5TR/P4Y/ 7922A5TR/P4Y 49.0 KN 56.0 KN 110 mm 0.877 kg 150 mm 20 mm
6386 7926A5TR/P4Y/ 7926A5TR/P4Y 74.0 KN 88.0 KN 130 mm 1.540 kg 180 mm 24 mm
6387 7932A5TR/P4Y/ 7932A5TR/P4Y 100 KN 125 KN 160 mm 3.120 kg 220 mm 28 mm
6388 7921A5TR/P4Y/ 7921A5TR/P4Y 48.0 KN 54.0 KN 105 mm 0.820 kg 145 mm 20 mm
6389 7924A5TR/P4Y/ 7924A5TR/P4Y 67.5 KN 77.0 KN 120 mm 1.150 kg 165 mm 22 mm
6390 7936A5TR/P4Y/ 7936A5TR/P4Y 137 KN 174 KN 180 mm 4.940 kg 250 mm 33 mm
6391 7930A5TR/P4Y/ 7930A5TR/P4Y 96.5 KN 115 KN 150 mm 2.970 kg 210 mm 28 mm
6392 7928A5TR/P4Y/ 7928A5TR/P4Y 75.0 KN 90.0 KN 140 mm 1.630 kg 190 mm 24 mm
6393 7934A5TR/P4Y/ 7934A5TR/P4Y 106 KN 140 KN 170 mm 3.360 kg 230 mm 28 mm
6394 7919A5TR/P4Y/ 7919A5TR/P4Y 40.0 KN 45.5 KN 95 mm 0.603 kg 130 mm 18 mm
6395 7920A5TR/P4Y/ 7920A5TR/P4Y 47.5 KN 51.5 KN 100 mm 0.808 kg 140 mm 20 mm
6396 7938A5TR/P4Y/ 7938A5TR/P4Y 139 KN 182 KN 190 mm 5.120 kg 260 mm 33 mm
6397 7919A5M/P4Y/ 7919A5M/P4Y 40.0 KN 45.5 KN 95 mm 0.603 kg 130 mm 18 mm
6398 7940A5TR/P4Y/ 7940A5TR/P4Y 178 KN 231 KN 200 mm 6.920 kg 280 mm 38 mm
6399 7922A5M/P4Y/ 7922A5M/P4Y 49.0 KN 56.0 KN 110 mm 0.877 kg 150 mm 20 mm
6400 7921A5M/P4Y/ 7921A5M/P4Y 48.0 KN 54.0 KN 105 mm 0.820 kg 145 mm 20 mm
