Spindellager

Das Bild kann vom Produkt abweichen. Weitere Informationen finden Sie in den technischen Daten.

Spindellager

Spindellager sind kritische Komponenten in Werkzeugmaschinen, Industrierobotern und schnell rotierenden Anlagen, die in erster Linie zur Lagerung und Führung der Spindelrotation dienen. Zu den gängigen Typen zählen Schrägkugellager, Zylinderrollenlager und Hybridkeramiklager, die sich durch hohe Präzision, hohe Steifigkeit und geringe Reibung auszeichnen. Sie erfüllen die Anforderungen an hohe Drehzahlen, hohe Belastungen und hervorragende Stabilität und spielen eine entscheidende Rolle in der Präzisionsbearbeitung, Luft- und Raumfahrt sowie in der Automatisierungsindustrie.

Standard

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh,DIN / VDEh

Innenringdurchmesser

10mm-280mm

Außenringdurchmesser

20mm-400mm

Gewicht

0.2kg-300kg

Material

GCr15, 52100, 100Cr6, SUJ2, Edelstahl, deutscher hochstickstoffhaltiger Edelstahl CRONIDUR30, Keramik

Marke

QIBR/OEM/Neutral

Anwendungen

Werkzeugmaschinenspindel, Zentrifuge, Druckerhöhungspumpe, Ölpumpe, Gebläse, verschiedene Getriebe, Laborgeräte

Verpackung

QIBR/Standard-Industrieverpackung/OEM

Paarungsmethode

DB, DF, DT, DBD, DBB, SU

Spindellager

Filter

Nr. Produkt Produktnummer Dynamische Tragzahl Statische Tragzahl Innendurchmesser (d) Masse Außendurchmesser (D) Breite (B)
6201 XC7021-CDLR-TX-P2/ XC7021-CDLR-TX-P2 95.6 KN 96.5 KN 105 mm 1.6 kg 160 mm 26 mm
6202 7228ATYNDBLP4/ 7228ATYNDBLP4 221 KN 240 KN 140 mm 8.15 kg 250 mm 42 mm
6203 XCB71921-E-P4S-U/ XCB71921-E-P4S-U 85.00 KN 42.50 KN 105 mm 0.7 kg 145 mm 20 mm
6204 XCB7021-E-P4S-U/ XCB7021-E-P4S-U 95.6 KN 96.5 KN 105 mm 1.6 kg 160 mm 26 mm
6205 B71921-C-P4S-U/ B71921-C-P4S-U 61.8 KN 69.5 KN 105 mm 0.82 kg 145 mm 20 mm
6206 B7021-C-P4S-U/ B7021-C-P4S-U 95.6 KN 96.5 KN 105 mm 1.6 kg 160 mm 26 mm
6207 HC7021-E-P4S-DB/ HC7021-E-P4S-DB 95.6 KN 96.5 KN 105 mm 1.6 kg 160 mm 26 mm
6208 XCB71921-C-P4S-DF/ XCB71921-C-P4S-DF 61.8 KN 69.5 KN 105 mm 0.82 kg 145 mm 20 mm
6209 XCB7021-C-P4S-DF/ XCB7021-C-P4S-DF 163.00 KN 72.00 KN 105 mm 1.3 kg 160 mm 26 mm
6210 XCB7021-C-P4S-U/ XCB7021-C-P4S-U 163.00 KN 72.00 KN 105 mm 1.3 kg 160 mm 26 mm
6211 XCB71921-C-P4S-U/ XCB71921-C-P4S-U 61.8 KN 69.5 KN 105 mm 0.82 kg 145 mm 20 mm
6212 B707-C-P4S-DF/ B707-C-P4S-DF 2.60 KN 1.14 KN 7 mm 0.008 kg 19 mm 6 mm
6213 B707-E-P4S-U/ B707-E-P4S-U 2.50 KN 1.10 KN 7 mm 0.008 kg 19 mm 6 mm
6214 XCB71921-C-P4S-DB/ XCB71921-C-P4S-DB 61.8 KN 69.5 KN 105 mm 0.82 kg 145 mm 20 mm
6215 XCB7021-C-P4S-DB/ XCB7021-C-P4S-DB 163.00 KN 72.00 KN 105 mm 1.3 kg 160 mm 26 mm
6216 HC7021-C-P4S-DB/ HC7021-C-P4S-DB 95.6 KN 96.5 KN 105 mm 1.6 kg 160 mm 26 mm
6217 B707-C-P4S-DB/ B707-C-P4S-DB 2.60 KN 1.14 KN 7 mm 0.008 kg 19 mm 6 mm
6218 XC7021-C-P4S-U/ XC7021-C-P4S-U 95.6 KN 96.5 KN 105 mm 1.6 kg 160 mm 26 mm
6219 B7221-C-P4S-DF/ B7221-C-P4S-DF 163 KN 146 KN 105 mm 3.85 kg 190 mm 36 mm
6220 B71921-C-P4S-DF/ B71921-C-P4S-DF 61.8 KN 69.5 KN 105 mm 0.82 kg 145 mm 20 mm
6221 XCB7021-E-P4S-DB/ XCB7021-E-P4S-DB 95.6 KN 96.5 KN 105 mm 1.6 kg 160 mm 26 mm
6222 B7021-C-P4S-DF/ B7021-C-P4S-DF 95.6 KN 96.5 KN 105 mm 1.6 kg 160 mm 26 mm
6223 XCB71921-E-P4S-DB/ XCB71921-E-P4S-DB 85.00 KN 42.50 KN 105 mm 0.7 kg 145 mm 20 mm
6224 HCB7021-E-P4S-U/ HCB7021-E-P4S-U 73.50 KN 72.00 KN 105 mm 1.3 kg 160 mm 26 mm
6225 B707-E-P4S-DF/ B707-E-P4S-DF 2.50 KN 1.10 KN 7 mm 0.008 kg 19 mm 6 mm
6226 XC7021-E-P4S-DB/ XC7021-E-P4S-DB 95.6 KN 96.5 KN 105 mm 1.6 kg 160 mm 26 mm
6227 XC7021-C-P4S-DB/ XC7021-C-P4S-DB 95.6 KN 96.5 KN 105 mm 1.6 kg 160 mm 26 mm
6228 B71921-C-P4S-DB/ B71921-C-P4S-DB 61.8 KN 69.5 KN 105 mm 0.82 kg 145 mm 20 mm
6229 XCB71921-E-P4S-DF/ XCB71921-E-P4S-DF 61.8 KN 69.5 KN 105 mm 0.82 kg 145 mm 20 mm
6230 XCB7021-E-P4S-DF/ XCB7021-E-P4S-DF 163.00 KN 72.00 KN 105 mm 1.3 kg 160 mm 26 mm
6231 B707-E-P2-DT/ B707-E-P2-DT 2.50 KN 1.10 KN 7 mm 0.008 kg 19 mm 6 mm
6232 707 707 ACE/HCP2 1.86 KN 0.62 KN 7 mm 0.007 kg 19 mm 6 mm
6233 B707-E-P2-DB-L/ B707-E-P2-DB-L 2.50 KN 1.10 KN 7 mm 0.008 kg 19 mm 6 mm
6234 XC71907-C-T-P4S/ XC71907-C-T-P4S 10.80 KN 4.40 KN 35 mm 0.080 kg 55 mm 10 mm
6235 XC71910-C-T-P4S/ XC71910-C-T-P4S 16.00 KN 7.20 KN 50 mm 0.140 kg 72 mm 12 mm
6236 XC7009-C-T-P4S/ XC7009-C-T-P4S 19.60 KN 8.50 KN 45 mm 0.260 kg 75 mm 16 mm
6237 XC71908-C-T-P4S/ XC71908-C-T-P4S 11.20 KN 4.80 KN 40 mm 0.120 kg 62 mm 12 mm
6238 XC71918-C-T-P4S/ XC71918-C-T-P4S 36.50 KN 19.60 KN 90 mm 0.580 kg 125 mm 18 mm
6239 XC7010-C-T-P4S/ XC7010-C-T-P4S 20.40 KN 9.15 KN 50 mm 0.270 kg 80 mm 16 mm
6240 XC71907-CDLR-T-P4S/ XC71907-CDLR-T-P4S 10.80 KN 4.40 KN 35 mm 0.080 kg 55 mm 10 mm
6241 XC71908-C-P4S-DF/ XC71908-C-P4S-DF 11.20 KN 4.80 KN 40 mm 0.120 kg 62 mm 12 mm
6242 XC71907-C-P4S-DF/ XC71907-C-P4S-DF 10.80 KN 4.40 KN 35 mm 0.080 kg 55 mm 10 mm
6243 XC7009-C-P4S-DF/ XC7009-C-P4S-DF 19.60 KN 8.50 KN 45 mm 0.260 kg 75 mm 16 mm
6244 XC71910-C-P4S-DF/ XC71910-C-P4S-DF 16.00 KN 7.20 KN 50 mm 0.140 kg 72 mm 12 mm
6245 XC7010-C-P4S-DF/ XC7010-C-P4S-DF 20.40 KN 9.15 KN 50 mm 0.270 kg 80 mm 16 mm
6246 XC71918-C-P4S-DF/ XC71918-C-P4S-DF 36.50 KN 19.60 KN 90 mm 0.580 kg 125 mm 18 mm
6247 XC71907-E-P4S-DF/ XC71907-E-P4S-DF 10.80 KN 4.40 KN 35 mm 0.080 kg 55 mm 10 mm
6248 XC71908-E-P4S-DF/ XC71908-E-P4S-DF 11.20 KN 4.80 KN 40 mm 0.120 kg 62 mm 12 mm
6249 XC7010-E-P4S-DF/ XC7010-E-P4S-DF 20.40 KN 9.15 KN 50 mm 0.270 kg 80 mm 16 mm
6250 XC7009-E-P4S-DF/ XC7009-E-P4S-DF 19.60 KN 8.50 KN 45 mm 0.260 kg 75 mm 16 mm
6251 XC71910-E-P4S-DF/ XC71910-E-P4S-DF 16.00 KN 7.20 KN 50 mm 0.140 kg 72 mm 12 mm
6252 XC71910-CDLR-T-P4S/ XC71910-CDLR-T-P4S 16.00 KN 7.20 KN 50 mm 0.140 kg 72 mm 12 mm
6253 XC7010-CDLR-T-P4S/ XC7010-CDLR-T-P4S 20.40 KN 9.15 KN 50 mm 0.270 kg 80 mm 16 mm
6254 XC71918-E-P4S-DF/ XC71918-E-P4S-DF 36.50 KN 19.60 KN 90 mm 0.580 kg 125 mm 18 mm
6255 XC7009-CDLR-T-P4S/ XC7009-CDLR-T-P4S 19.60 KN 8.50 KN 45 mm 0.260 kg 75 mm 16 mm
6256 XC71908-CDLR-T-P4S/ XC71908-CDLR-T-P4S 11.20 KN 4.80 KN 40 mm 0.120 kg 62 mm 12 mm
6257 XC71918-CDLR-T-P4S/ XC71918-CDLR-T-P4S 36.50 KN 19.60 KN 90 mm 0.580 kg 125 mm 18 mm
6258 XC71910-C-T-P4S/ XC71910-C-T-P4S 16.00 KN 7.20 KN 50 mm 0.140 kg 72 mm 12 mm
6259 XC7009-CDLR-TX-P2/ XC7009-CDLR-TX-P2 19.60 KN 8.50 KN 45 mm 0.260 kg 75 mm 16 mm
6260 XC71910-CDLR-TX-P2/ XC71910-CDLR-TX-P2 16.00 KN 7.20 KN 50 mm 0.140 kg 72 mm 12 mm
6261 XC7010-CDLR-TX-P2/ XC7010-CDLR-TX-P2 20.40 KN 9.15 KN 50 mm 0.270 kg 80 mm 16 mm
6262 XC71918-CDLR-TX-P2/ XC71918-CDLR-TX-P2 36.50 KN 19.60 KN 90 mm 0.580 kg 125 mm 18 mm
6263 XC71907-CDLR-TX-P2/ XC71907-CDLR-TX-P2 10.80 KN 4.40 KN 35 mm 0.080 kg 55 mm 10 mm
6264 XC71908-CDLR-TX-P2/ XC71908-CDLR-TX-P2 11.20 KN 4.80 KN 40 mm 0.120 kg 62 mm 12 mm
6265 XC71908-C-P4S-DB/ XC71908-C-P4S-DB 11.20 KN 4.80 KN 40 mm 0.120 kg 62 mm 12 mm
6266 XC7009-C-P4S-U/ XC7009-C-P4S-U 19.60 KN 8.50 KN 45 mm 0.260 kg 75 mm 16 mm
6267 XC7010-C-P4S-U/ XC7010-C-P4S-U 20.40 KN 9.15 KN 50 mm 0.270 kg 80 mm 16 mm
6268 XC71910-C-P4S-DB/ XC71910-C-P4S-DB 16.00 KN 7.20 KN 50 mm 0.140 kg 72 mm 12 mm
6269 XC7009-C-P4S-DB/ XC7009-C-P4S-DB 19.60 KN 8.50 KN 45 mm 0.260 kg 75 mm 16 mm
6270 XC7010-C-P4S-DB/ XC7010-C-P4S-DB 20.40 KN 9.15 KN 50 mm 0.270 kg 80 mm 16 mm
6271 XC71907-E-P4S-DB/ XC71907-E-P4S-DB 10.80 KN 4.40 KN 35 mm 0.080 kg 55 mm 10 mm
6272 XC7009-E-P4S-DB/ XC7009-E-P4S-DB 19.60 KN 8.50 KN 45 mm 0.260 kg 75 mm 16 mm
6273 XC71908-E-P4S-DB/ XC71908-E-P4S-DB 11.20 KN 4.80 KN 40 mm 0.120 kg 62 mm 12 mm
6274 XC71910-E-P4S-DB/ XC71910-E-P4S-DB 16.00 KN 7.20 KN 50 mm 0.140 kg 72 mm 12 mm
6275 XC7010-E-P4S-DB/ XC7010-E-P4S-DB 20.40 KN 9.15 KN 50 mm 0.270 kg 80 mm 16 mm
6276 XC71918-E-P4S-DB/ XC71918-E-P4S-DB 36.50 KN 19.60 KN 90 mm 0.580 kg 125 mm 18 mm
6277 XC71918-C-P4S-DB/ XC71918-C-P4S-DB 36.50 KN 19.60 KN 90 mm 0.580 kg 125 mm 18 mm
6278 XC71907-C-P4S-DB/ XC71907-C-P4S-DB 10.80 KN 4.40 KN 35 mm 0.080 kg 55 mm 10 mm
6279 HCB707-EDLR-T-P4S/ HCB707-EDLR-T-P4S 1.73 KN 0.77 KN 7 mm 0.007 kg 19 mm 6 mm
6280 HCB707-C-P2-DT-L/ HCB707-C-P2-DT-L 1.73 KN 0.77 KN 7 mm 0.007 kg 19 mm 6 mm
6281 HCB707-E-P2-DB/ HCB707-E-P2-DB 1.73 KN 0.77 KN 7 mm 0.007 kg 19 mm 6 mm
6282 HCB707-C-T-P4S/ HCB707-C-T-P4S 1.80 KN 0.80 KN 7 mm 0.007 kg 19 mm 6 mm
6283 HCB707-E-T-P4S/ HCB707-E-T-P4S 1.73 KN 0.77 KN 7 mm 0.007 kg 19 mm 6 mm
6284 HCB707-C-P4S-U/ HCB707-C-P4S-U 1.80 KN 0.80 KN 7 mm 0.007 kg 19 mm 6 mm
6285 HCB707-C-DLR-T-P4S/ HCB707-C-DLR-T-P4S 1.80 KN 0.80 KN 7 mm 0.007 kg 19 mm 6 mm
6286 HCB707-E-P4S-U/ HCB707-E-P4S-U 1.73 KN 0.77 KN 7 mm 0.007 kg 19 mm 6 mm
6287 HCB707-E-P4S-U/ HCB707-E-P4S-U 1.73 KN 0.77 KN 7 mm 0.007 kg 19 mm 6 mm
6288 XC707-C-P2-DB-M/ XC707-C-P2-DB-M 4.05 KN 0.8 KN 7 mm 0.007 kg 19 mm 6 mm
6289 XCB707-C-P2-DT/ XCB707-C-P2-DT 4.05 KN 0.8 KN 7 mm 0.007 kg 19 mm 6 mm
6290 XCB707-E-P2-DT-M/ XCB707-E-P2-DT-M 4.05 KN 0.8 KN 7 mm 0.007 kg 19 mm 6 mm
6291 XC707-C-P2-DT/ XC707-C-P2-DT 4.05 KN 0.8 KN 7 mm 0.007 kg 19 mm 6 mm
6292 XC707-C-P2-H/ XC707-C-P2-H 4.05 KN 0.8 KN 7 mm 0.007 kg 19 mm 6 mm
6293 XC707-E-P2-DT-M/ XC707-E-P2-DT-M 4.05 KN 0.8 KN 7 mm 0.007 kg 19 mm 6 mm
6294 XCB707-C-P2-DB-M/ XCB707-C-P2-DB-M 4.05 KN 0.8 KN 7 mm 0.007 kg 19 mm 6 mm
6295 XC707-C-T-P4S/ XC707-C-T-P4S 4.05 KN 0.8 KN 7 mm 0.007 kg 19 mm 6 mm
6296 XC707-E-T-P4S/ XC707-E-T-P4S 4.05 KN 0.8 KN 7 mm 0.007 kg 19 mm 6 mm
6297 XC707-EDLR-T-P4S/ XC707-EDLR-T-P4S 4.05 KN 0.8 KN 7 mm 0.007 kg 19 mm 6 mm
6298 XC707-CDLR-T-P4S/ XC707-CDLR-T-P4S 4.05 KN 0.8 KN 7 mm 0.007 kg 19 mm 6 mm
6299 XC707-C-P4S-DF/ XC707-C-P4S-DF 4.05 KN 0.8 KN 7 mm 0.007 kg 19 mm 6 mm
6300 XC707-E-P4S-DF/ XC707-E-P4S-DF 4.05 KN 0.8 KN 7 mm 0.007 kg 19 mm 6 mm
