SERIE 70. 70. 718. 719

Das Bild kann vom Produkt abweichen. Weitere Informationen finden Sie in den technischen Daten.

SERIE 70. 70. 718. 719

Die verbesserte Lagerkinematik und höhere Qualität der Laufbahn können die Reibung, Lagertemperaturen und Schmierbedarf verringern.

Standard

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh,DIN / VDEh

Innenringdurchmesser

10mm-280mm

Außenringdurchmesser

20mm-400mm

Gewicht

0.2kg-300kg

Material

GCr15, 52100, 100Cr6, SUJ2, Edelstahl, Deutscher Edelstahl mit hohem Stickstoffgehalt CRONIDUR30, Keramik

Marke

QIBR/OEM/Neutral

Verpackung

QIBR/Standard-Industrieverpackung/OEM

Anwendungen

Werkzeugmaschinenspindel, Zentrifuge, Druckerhöhungspumpe, Ölpumpe, Gebläse, verschiedene Getriebe, Laborgerät

Paarungsmethode

DB, DF, DT, DBD, DBB, SU

SERIE 70. 70. 718. 719

Filter

Nr. Produkt Produktnummer Dynamische Tragzahl Statische Tragzahl Innendurchmesser (d) Masse Außendurchmesser (D) Breite (B)
701 7002CE/HCP4A/ 7002CE/HCP4A 4.42 KN 1.93 KN 15 mm 0.025 kg 32 mm 9 mm
702 7001ACE/HCP4A/ 7001ACE/HCP4A 3.07 KN 1.27 KN 12 mm 0.019 kg 28 mm 8 mm
703 71902CE/HCP4A/ 71902CE/HCP4A 3.19 KN 1.4 KN 15 mm 0.013 kg 28 mm 7 mm
704 729CD/HCP4A/ 729CD/HCP4A 4.1 KN 1.66 KN 9 mm 0.018 kg 26 mm 8 mm
705 71900ACE/P4AHU/ 71900ACE/P4AHU 1.95 KN 0.78 KN 10 mm 0.009 kg 22 mm 6 mm
706 728CD/HCP4A/ 728CD/HCP4A 3.71 KN 1.37 KN 8 mm 0.015 kg 24 mm 8 mm
707 709CD/HCP4A/ 709CD/HCP4A 3.58 KN 1.6 KN 9 mm 0.013 kg 24 mm 7 mm
708 71901ACE/HCP4A/ 71901ACE/HCP4A 2.03 KN 0.865 KN 12 mm 0.009 kg 24 mm 6 mm
709 7000ACE/HCP4A/ 7000ACE/HCP4A 2.86 KN 1.14 KN 10 mm 0.017 kg 26 mm 8 mm
710 709ACE/P4AHU/ 709ACE/P4AHU 2.51 KN 0.9 KN 9 mm 0.014 kg 24 mm 7 mm
711 727CD/HCP4A/ 727CD/HCP4A 2.96 KN 1.16 KN 7 mm 0.012 kg 22 mm 7 mm
712 708CD/HCP4A/ 708CD/HCP4A 3.25 KN 1.37 KN 8 mm 0.011 kg 22 mm 7 mm
713 719/9ACE/P4AHU/ 719/9ACE/P4AHU 1.95 KN 0.765 KN 9 mm 0.008 kg 20 mm 6 mm
714 708ACE/HP4AU/ 708ACE/HP4AU 2.29 KN 0.765 KN 8 mm 0.012 kg 22 mm 7 mm
715 71900ACE/HCP4A/ 71900ACE/HCP4A 1.95 KN 0.78 KN 10 mm 0.008 kg 22 mm 6 mm
716 709ACE/HCP4A/ 709ACE/HCP4A 2.51 KN 0.9 KN 9 mm 0.013 kg 24 mm 7 mm
717 71901CE/HCP4A/ 71901CE/HCP4A 2.12 KN 0.915 KN 12 mm 0.009 kg 24 mm 6 mm
718 707CD/HCP4A/ 707CD/HCP4A 2.51 KN 0.98 KN 7 mm 0.007 kg 19 mm 6 mm
719 7000CE/HCP4A/ 7000CE/HCP4A 3.02 KN 1.18 KN 10 mm 0.017 kg 26 mm 8 mm
720 71900CE/HCP4A/ 71900CE/HCP4A 2.03 KN 0.815 KN 10 mm 0.008 kg 22 mm 6 mm
721 719/9ACE/HCP4A/ 719/9ACE/HCP4A 1.95 KN 0.765 KN 9 mm 0.007 kg 20 mm 6 mm
722 708ACE/HCP4A/ 708ACE/HCP4A 2.29 KN 0.765 KN 8 mm 0.011 kg 22 mm 7 mm
723 719/8ACE/P4AHU/ 719/8ACE/P4AHU 1.68 KN 0.6 KN 8 mm 0.007 kg 19 mm 6 mm
724 719/9CE/HCP4A/ 719/9CE/HCP4A 2.03 KN 0.8 KN 9 mm 0.007 kg 20 mm 6 mm
725 707ACE/P4AHU/ 707ACE/P4AHU 1.86 KN 0.62 KN 7 mm 0.007 kg 19 mm 6 mm
726 719/8ACE/HCP4A/ 719/8ACE/HCP4A 1.68KN 0.6 KN 8 mm 0.006 kg 19 mm 6 mm
727 707ACE/HCP4A/ 707ACE/HCP4A 1.86 KN 0.62 KN 7 mm 0.006 kg 19 mm 6 mm
728 709CE/HCP4A/ 709CE/HCP4A 2.6 KN 0.93 KN 9 mm 0.013 kg 24 mm 7 mm
729 719/8CE/HCP4A/ 719/8CE/HCP4A 1.74 KN 0.63 KN 8 mm 0.006 kg 19 mm 6 mm
730 706ACE/HCP4A/ 706ACE/HCP4A 1.51 KN 0.49 KN 6 mm 0.005 kg 17 mm 6 mm
731 708CE/HCP4A/ 708CE/HCP4A 2.34 KN 0.8 KN 8 mm 0.011 kg 22 mm 7 mm
732 706CD/HCP4A/ 706CD/HCP4A 2.03 KN 0.765 KN 6 mm 0.005 kg 17 mm 6 mm
733 706ACE/P4AHU/ 706ACE/P4AHU 1.51 KN 0.49 KN 6 mm 0.006 kg 17 mm 6 mm
734 707CE/HCP4A/ 707CE/HCP4A 1.95 KN 0.64 KN 7 mm 0.006 kg 19 mm 6 mm
735 706CE/HCP4A/ 706CE/HCP4A 1.56 KN 0.5 KN 6 mm 0.005 kg 17 mm 6 mm
736 XCB706-E-P2-TBT/ XCB706-E-P2-TBT 3.45 KN 0.66 KN 6 mm 0.004 kg 17 mm 6 mm
737 XCB706E/ XCB706E 3.45 KN 0.66 KN 6 mm 0.004 kg 17 mm 6 mm
738 7906CSN24/ 7906CSN24 8.30 KN 6.25 KN 30 mm 0.049 kg 47 mm 9 mm
739 7230ASN24TYNDBLP4/ 7230ASN24TYNDBLP4 248 KN 280 KN 150 mm 11.200 kg 270 mm 45 mm
740 7228ASN24TYNDBLP4/ 7228ASN24TYNDBLP4 218 KN 234 KN 140 mm 7.970 kg 250 mm 42 mm
741 725ATYNDBLP4/ 725ATYNDBLP4 1.610 KN 0.620 KN 5 mm 4.5 g 16 mm 5 mm
742 726ATYNDBLP4/ 726ATYNDBLP4 2.240 KN 0.940 KN 6 mm 7.8 g 19 mm 6 mm
743 7222ASN24TYNDBLP4/ 7222ASN24TYNDBLP4 162 KN 148 KN 110 mm 4.490 kg 200 mm 38 mm
744 7221ASN24TYNDBLP4/ 7221ASN24TYNDBLP4 150 KN 132 KN 105 mm 3.820 kg 190 mm 36 mm
745 7217ASN24TYNDBLP4/ 7217ASN24TYNDBLP4 98.5 KN 83.5 KN 85 mm 1.800 kg 150 mm 28 mm
746 7216ASN24TYNDBLP4/ 7216ASN24TYNDBLP4 85.5 KN 71.5 KN 80 mm 1.450 kg 140 mm 26 mm
747 7226ASN24TYNDBLP4/ 7226ASN24TYNDBLP4 189 KN 193 KN 130 mm 6.280 kg 230 mm 40 mm
748 7224ASN24TYNDBLP4/ 7224ASN24TYNDBLP4 183 KN 177 KN 120 mm 5.450 kg 215 mm 40 mm
749 7220ASN24TYNDBLP4/ 7220ASN24TYNDBLP4 137 KN 117 KN 100 mm 3.210 kg 180 mm 34 mm
750 7219ASN24TYNDBLP4/ 7219ASN24TYNDBLP4 122 KN 103 KN 95 mm 2.670 kg 170 mm 32 mm
751 7218ASN24TYNDBLP4/ 7218ASN24TYNDBLP4 113 KN 96.5 KN 90 mm 2.230 kg 160 mm 30 mm
752 7215ASN24TYNDBLP4/ 7215ASN24TYNDBLP4 76.0 KN 64.5 KN 75 mm 1.200 kg 130 mm 25 mm
753 7214ASN24TYNDBLP4/ 7214ASN24TYNDBLP4 73.0 KN 59.5 KN 70 mm 1.100 kg 125 mm 24 mm
754 7213ASN24TYNDBLP4/ 7213ASN24TYNDBLP4 67.5 KN 54.0 KN 65 mm 1.020 kg 120 mm 23 mm
755 7212ASN24TYNDBLP4/ 7212ASN24TYNDBLP4 59.0 KN 45.5 KN 60 mm 0.789 kg 110 mm 22 mm
756 7209ASN24TYNDBLP4/ 7209ASN24TYNDBLP4 37.5 KN 26.7 KN 45 mm 0.410 kg 85 mm 19 mm
757 7208ASN24TYNDBLP4/ 7208ASN24TYNDBLP4 33.5 KN 23.3 KN 40 mm 0.370 kg 80 mm 18 mm
758 7211ASN24TYNDBLP4/ 7211ASN24TYNDBLP4 49.0 KN 37.0 KN 55 mm 0.609 kg 100 mm 21 mm
759 7204ASN24TYNDBLP4/ 7204ASN24TYNDBLP4 13.6 KN 7.55 KN 20 mm 0.104 kg 47 mm 14 mm
760 7206ASN24TYNDBLP4/ 7206ASN24TYNDBLP4 21.3 KN 13.6 KN 30 mm 0.197 kg 62 mm 16 mm
761 7205ASN24TYNDBLP4/ 7205ASN24TYNDBLP4 15.4 KN 9.45 KN 25 mm 0.129 kg 52 mm 15 mm
762 7210ASN24TYNDBLP4/ 7210ASN24TYNDBLP4 39.5 KN 29.3 KN 50 mm 0.462 kg 90 mm 20 mm
763 7207ASN24TYNDBLP4/ 7207ASN24TYNDBLP4 28.2 KN 18.5 KN 35 mm 0.284 kg 72 mm 17 mm
764 7034ASN24TYNDBLP4/ 7034ASN24TYNDBLP4 186 KN 214 KN 170 mm 6.940 kg 260 mm 42 mm
765 7032ASN24TYNDBLP4/ 7032ASN24TYNDBLP4 155 KN 176 KN 160 mm 5.160 kg 240 mm 38 mm
766 7200ASN24TYNDBLP4/ 7200ASN24TYNDBLP4 5.05 KN 2.44 KN 10 mm 0.032 kg 30 mm 9 mm
767 7040ASN24TYNDBLP4/ 7040ASN24TYNDBLP4 240 KN 310 KN 200 mm 13.70 kg 310 mm 51 mm
768 7038ASN24TYNDBLP4/ 7038ASN24TYNDBLP4 224 KN 280 KN 190 mm 11.30 kg 290 mm 46 mm
769 7036ASN24TYNDBLP4/ 7036ASN24TYNDBLP4 207 KN 252 KN 180 mm 9.270 kg 280 mm 46 mm
770 7030ASN24TYNDBLP4/ 7030ASN24TYNDBLP4 137 KN 154 KN 150 mm 4.190 kg 225 mm 35 mm
771 7203ASN24TYNDBLP4/ 7203ASN24TYNDBLP4 10.1 KN 5.45 KN 17 mm 0.065 kg 40 mm 12 mm
772 7202ASN24TYNDBLP4/ 7202ASN24TYNDBLP4 8.10 KN 4.25 KN 15 mm 0.045 kg 35 mm 11 mm
773 7201ASN24TYNDBLP4/ 7201ASN24TYNDBLP4 7.45 KN 3.65 KN 12 mm 0.030 kg 32 mm 10 mm
774 7019ASN24TYNDBLP4/ 7019ASN24TYNDBLP4 67.0 KN 67.0 KN 95 mm 1.230 kg 145 mm 24 mm
775 7018ASN24TYNDBLP4/ 7018ASN24TYNDBLP4 65.0 KN 63.5 KN 90 mm 1.180 kg 140 mm 24 mm
776 7017ASN24TYNDBLP4/ 7017ASN24TYNDBLP4 54.5 KN 53.5 KN 85 mm 0.907 kg 130 mm 22 mm
777 7021ASN24TYNDBLP4/ 7021ASN24TYNDBLP4 80.0 KN 81.5 KN 105 mm 1.600 kg 160 mm 26 mm
778 7020ASN24TYNDBLP4/ 7020ASN24TYNDBLP4 68.5 KN 70.5 KN 100 mm 1.280 kg 150 mm 24 mm
779 7028ASN24TYNDBLP4/ 7028ASN24TYNDBLP4 120 KN 133 KN 140 mm 3.440 kg 210 mm 33 mm
780 7026ASN24TYNDBLP4/ 7026ASN24TYNDBLP4 117 KN 125 KN 130 mm 3.260 kg 200 mm 33 mm
781 7024ASN24TYNDBLP4/ 7024ASN24TYNDBLP4 102 KN 107 KN 120 mm 2.120 kg 180 mm 28 mm
782 7022ASN24TYNDBLP4/ 7022ASN24TYNDBLP4 96.5 KN 95.5 KN 110 mm 1.960 kg 170 mm 28 mm
783 7016ASN24TYNDBLP4/ 7016ASN24TYNDBLP4 53.5 KN 50.5 KN 80 mm 0.864 kg 125 mm 22 mm
784 7015ASN24TYNDBLP4/ 7015ASN24TYNDBLP4 43.5 KN 41.5 KN 75 mm 0.650 kg 115 mm 20 mm
785 7013ASN24TYNDBLP4/ 7013ASN24TYNDBLP4 33.5 KN 31.5 KN 65 mm 0.441 kg 100 mm 18 mm
786 7012ASN24TYNDBLP4/ 7012ASN24TYNDBLP4 32.0 KN 28.1 KN 60 mm 0.410 kg 95 mm 18 mm
787 7008ASN24TYNDBLP4/ 7008ASN24TYNDBLP4 18.8 KN 14.6 KN 40 mm 0.191 kg 68 mm 15 mm
788 7011ASN24TYNDBLP4/ 7011ASN24TYNDBLP4 31.0 KN 26.3 KN 55 mm 0.385 kg 90 mm 18 mm
789 7010ASN24TYNDBLP4/ 7010ASN24TYNDBLP4 23.7 KN 20.1 KN 50 mm 0.262 kg 80 mm 16 mm
790 7009ASN24TYNDBLP4/ 7009ASN24TYNDBLP4 22.3 KN 17.7 KN 45 mm 0.241 kg 75 mm 16 mm
791 7014ASN24TYNDBLP4/ 7014ASN24TYNDBLP4 42.5 KN 39.5 KN 70 mm 0.613 kg 110 mm 20 mm
792 7005ASN24TYNDBLP4/ 7005ASN24TYNDBLP4 10.7 KN 6.85 KN 25 mm 0.079 kg 47 mm 12 mm
793 7004ASN24TYNDBLP4/ 7004ASN24TYNDBLP4 10.3 KN 6.10 KN 20 mm 0.068 kg 42 mm 12 mm
794 7007ASN24TYNDBLP4/ 7007ASN24TYNDBLP4 17.5 KN 12.6 KN 35 mm 0.153 kg 62 mm 14 mm
795 7006ASN24TYNDBLP4/ 7006ASN24TYNDBLP4 13.9 KN 9.45 KN 30 mm 0.116 kg 55 mm 13 mm
796 7003ASN24TYNDBLP4/ 7003ASN24TYNDBLP4 6.10 KN 3.50 KN 17 mm 0.040 kg 35 mm 10 mm
797 7002ASN24TYNDBLP4/ 7002ASN24TYNDBLP4 6.25 KN 3.40 KN 15 mm 0.030 kg 32 mm 9 mm
798 7000ASN24TYNDBLP4/ 7000ASN24TYNDBLP4 5.30 KN 2.49 KN 10 mm 0.019 kg 26 mm 8 mm
799 7001ASN24TYNDBLP4/ 7001ASN24TYNDBLP4 5.80 KN 2.90 KN 12 mm 0.021 kg 28 mm 8 mm
800 728ASN24TYNDBLP4/ 728ASN24TYNDBLP4 3.600 KN 1.580 KN 8 mm 16.0 g 24 mm 8 mm
