SERIE 70. 70. 718. 719

Das Bild kann vom Produkt abweichen. Weitere Informationen finden Sie in den technischen Daten.

SERIE 70. 70. 718. 719

Die verbesserte Lagerkinematik und höhere Qualität der Laufbahn können die Reibung, Lagertemperaturen und Schmierbedarf verringern.

Standard

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh,DIN / VDEh

Innenringdurchmesser

10mm-280mm

Außenringdurchmesser

20mm-400mm

Gewicht

0.2kg-300kg

Material

GCr15, 52100, 100Cr6, SUJ2, Edelstahl, Deutscher Edelstahl mit hohem Stickstoffgehalt CRONIDUR30, Keramik

Marke

QIBR/OEM/Neutral

Verpackung

QIBR/Standard-Industrieverpackung/OEM

Anwendungen

Werkzeugmaschinenspindel, Zentrifuge, Druckerhöhungspumpe, Ölpumpe, Gebläse, verschiedene Getriebe, Laborgerät

Paarungsmethode

DB, DF, DT, DBD, DBB, SU

SERIE 70. 70. 718. 719

Filter

Nr. Produkt Produktnummer Dynamische Tragzahl Statische Tragzahl Innendurchmesser (d) Masse Außendurchmesser (D) Breite (B)
401 7014CE/HCP4A/ 7014CE/HCP4A 23.8 KN 18.3 KN 70 mm 0.56 kg 110 mm 20 mm
402 708ACE/HP4AU/ 708ACE/HP4AU 2.29 KN 0.765 KN 8 mm 0.012 kg 22 mm 7 mm
403 719/8ACE/P4AHU/ 719/8ACE/P4AHU 1.68 KN 0.6 KN 8 mm 0.007 kg 19 mm 6 mm
404 719/9CE/HCP4A/ 719/9CE/HCP4A 2.03 KN 0.8 KN 9 mm 0.007 kg 20 mm 6 mm
405 71900CE/HCP4A/ 71900CE/HCP4A 2.03 KN 0.815 KN 10 mm 0.008 kg 22 mm 6 mm
406 709ACE/HCP4A/ 709ACE/HCP4A 2.51 KN 0.9 KN 9 mm 0.013 kg 24 mm 7 mm
407 71914CE/HCP4A/ 71914CE/HCP4A 22.1 KN 16.3 KN 70 mm 0.27 kg 100 mm 16 mm
408 708ACE/HCP4A/ 708ACE/HCP4A 2.29 KN 0.765 KN 8 mm 0.011 kg 22 mm 7 mm
409 71924CE/HCP4A/ 71924CE/HCP4A 47.5 KN 40.5 KN 120 mm 0.93 kg 165 mm 22 mm
410 71920CD/HCP4A/ 71920CD/HCP4A 60.5 KN 65.5 KN 100 mm 0.67 kg 140 mm 20 mm
411 719/9ACE/HCP4A/ 719/9ACE/HCP4A 1.95 KN 0.765 KN 9 mm 0.007 kg 20 mm 6 mm
412 7211CD/HCP4A/ 7211CD/HCP4A 55.3 KN 43 KN 55 mm 0.51 kg 100 mm 21 mm
413 71918CD/HCP4A/ 71918CD/HCP4A 47.5 KN 51 KN 90 mm 0.47 kg 125 mm 18 mm
414 71901CE/HCP4A/ 71901CE/HCP4A 2.12 KN 0.915 KN 12 mm 0.009 kg 24 mm 6 mm
415 7212CD/HCP4A/ 7212CD/HCP4A 57.2 KN 46.5 KN 60 mm 0.69 kg 110 mm 22 mm
416 719/9ACE/P4AHU/ 719/9ACE/P4AHU 1.95 KN 0.765 KN 9 mm 0.008 kg 20 mm 6 mm
417 727CD/HCP4A/ 727CD/HCP4A 2.96 KN 1.16 KN 7 mm 0.012 kg 22 mm 7 mm
418 728CD/HCP4A/ 728CD/HCP4A 3.71 KN 1.37 KN 8 mm 0.015 kg 24 mm 8 mm
419 708CD/HCP4A/ 708CD/HCP4A 3.25 KN 1.37 KN 8 mm 0.011 kg 22 mm 7 mm
420 71900ACE/HCP4A/ 71900ACE/HCP4A 1.95 KN 0.78 KN 10 mm 0.008 kg 22 mm 6 mm
421 7000ACE/HCP4A/ 7000ACE/HCP4A 2.86 KN 1.14 KN 10 mm 0.017 kg 26 mm 8 mm
422 709ACE/P4AHU/ 709ACE/P4AHU 2.51 KN 0.9 KN 9 mm 0.014 kg 24 mm 7 mm
423 71901ACE/HCP4A/ 71901ACE/HCP4A 2.03 KN 0.865 KN 12 mm 0.009 kg 24 mm 6 mm
424 7015CE/HCP4A/ 7015CE/HCP4A 26 KN 21.6 KN 75 mm 0.59 kg 115 mm 20 mm
425 707CD/HCP4A/ 707CD/HCP4A 2.51 KN 0.98 KN 7 mm 0.007 kg 19 mm 6 mm
426 7020CD/HCP4A/ 7020CD/HCP4A 83.2 KN 85 KN 100 mm 1.05 kg 150 mm 24 mm
427 71913CD/HCP4A/ 71913CD/HCP4A 20.8 KN 17 KN 65 mm 0.17 kg 90 mm 13 mm
428 729CD/HCP4A/ 729CD/HCP4A 4.1 KN 1.66 KN 9 mm 0.018 kg 26 mm 8 mm
429 71900ACE/P4AHU/ 71900ACE/P4AHU 1.95 KN 0.78 KN 10 mm 0.009 kg 22 mm 6 mm
430 71922ACE/HCP4A/ 71922ACE/HCP4A 37.7 KN 32.5 KN 110 mm 0.7 kg 150 mm 20 mm
431 7000ACE/P4AHU/ 7000ACE/P4AHU 2.86 KN 1.14 KN 10 mm 0.019 kg 26 mm 8 mm
432 709CD/HCP4A/ 709CD/HCP4A 3.58 KN 1.6 KN 9 mm 0.013 kg 24 mm 7 mm
433 71902CE/HCP4A/ 71902CE/HCP4A 3.19 KN 1.4 KN 15 mm 0.013 kg 28 mm 7 mm
434 7001ACE/HCP4A/ 7001ACE/HCP4A 3.07 KN 1.27 KN 12 mm 0.019 kg 28 mm 8 mm
435 71900CD/HCP4A/ 71900CD/HCP4A 2.51 KN 1.1 KN 10 mm 0.009 kg 22 mm 6 mm
436 7002CE/HCP4A/ 7002CE/HCP4A 4.42 KN 1.93 KN 15 mm 0.025 kg 32 mm 9 mm
437 71902ACE/HCP4A/ 71902ACE/HCP4A 3.02 KN 1.34 KN 15 mm 0.013 kg 28 mm 7 mm
438 7002ACE/HCP4A/ 7002ACE/HCP4A 4.23 KN 1.83 KN 15 mm 0.025 kg 32 mm 9 mm
439 71901ACE/P4AHU/ 71901ACE/P4AHU 2.03 KN 0.865 KN 12 mm 0.01 kg 24 mm 6 mm
440 71903CE/HCP4A/ 71903CE/HCP4A 3.32 KN 1.56 KN 17 mm 0.014 kg 30 mm 7 mm
441 7001ACE/P4AHU/ 7001ACE/P4AHU 3.07 KN 1.27 KN 12 mm 0.021 kg 28 mm 8 mm
442 71915CE/HCP4A/ 71915CE/HCP4A 22.5 KN 17 KN 75 mm 0.29 kg 105 mm 16 mm
443 71903ACE/HCP4A/ 71903ACE/HCP4A 3.19 KN 1.46 KN 17 mm 0.014 kg 30 mm 7 mm
444 7200CD/HCP4A/ 7200CD/HCP4A 4.49 KN 1.93 KN 10 mm 0.029 kg 30 mm 9 mm
445 71901CD/HCP4A/ 71901CD/HCP4A 2.65 KN 1.25 KN 12 mm 0.01 kg 24 mm 6 mm
446 71903ACE/P4AHU/ 71903ACE/P4AHU 3.19 KN 1.46 KN 17 mm 0.016 kg 30 mm 7 mm
447 71902CD/HCP4A/ 71902CD/HCP4A 3.97 KN 1.9 KN 15 mm 0.014 kg 28 mm 7 mm
448 7002ACE/P4AHU/ 7002ACE/P4AHU 4.23 KN 1.83 KN 15 mm 0.028 kg 32 mm 9 mm
449 7003ACE/P4AHU/ 7003ACE/P4AHU 5.59 KN 2.45 KN 17 mm 0.035 kg 35 mm 10 mm
450 7022ACE/HCP4A/ 7022ACE/HCP4A 44.9 KN 42.5 KN 110 mm 1.95 kg 170 mm 28 mm
451 7001CD/HCP4A/ 7001CD/HCP4A 4.49 KN 1.9 KN 12 mm 0.018 kg 28 mm 8 mm
452 7220CD/HCP4A/ 7220CD/HCP4A 156 KN 137 KN 100 mm 2.7 kg 180 mm 34 mm
453 7201CD/HCP4A/ 7201CD/HCP4A 5.85 KN 2.55 KN 12 mm 0.033 kg 32 mm 10 mm
454 7018CD/HCP4A/ 7018CD/HCP4A 79.3 KN 76.5 KN 90 mm 1 kg 140 mm 24 mm
455 7004CE/HCP4A/ 7004CE/HCP4A 7.41 KN 3.35 KN 20 mm 0.056 kg 42 mm 12 mm
456 7004ACE/HCP4A/ 7004ACE/HCP4A 7.15 KN 3.25 KN 20 mm 0.056 kg 42 mm 12 mm
457 71904ACE/HCP4A/ 71904ACE/HCP4A 4.68 KN 2.28 KN 20 mm 0.032 kg 37 mm 9 mm
458 7002CD/HCP4A/ 7002CD/HCP4A 5.2 KN 2.45 KN 15 mm 0.027 kg 32 mm 9 mm
459 71904CE/HCP4A/ 71904CE/HCP4A 4.88 KN 2.4 KN 20 mm 0.032 kg 37 mm 9 mm
460 7202CD/HCP4A/ 7202CD/HCP4A 7.41 KN 3.35 KN 15 mm 0.037 kg 35 mm 11 mm
461 71904ACE/P4AHU/ 71904ACE/P4AHU 4.68 KN 2.28 KN 20 mm 0.036 kg 37 mm 9 mm
462 7003CD/HCP4A/ 7003CD/HCP4A 6.76 KN 3.25 KN 17 mm 0.033 kg 35 mm 10 mm
463 71905ACE/HCP4A/ 71905ACE/HCP4A 4.94 KN 2.7 KN 25 mm 0.036 kg 42 mm 9 mm
464 71905CE/HCP4A/ 71905CE/HCP4A 5.27 KN 2.85 KN 25 mm 0.036 kg 42 mm 9 mm
465 71905ACE/P4AHU/ 71905ACE/P4AHU 4.94 KN 2.7 KN 25 mm 0.04 kg 42 mm 9 mm
466 7004ACE/P4AHU/ 7004ACE/P4AHU 7.15 KN 3.25 KN 20 mm 0.064 kg 42 mm 12 mm
467 7005ACE/HCP4A/ 7005ACE/HCP4A 7.93 KN 3.9 KN 25 mm 0.065 kg 47 mm 12 mm
468 71903CD/HCP4A/ 71903CD/HCP4A 4.16 KN 2.08 KN 17 mm 0.015 kg 30 mm 7 mm
469 71906ACE/HCP4A/ 71906ACE/HCP4A 5.27 KN 3.1 KN 30 mm 0.045 kg 47 mm 9 mm
470 71914CD/HCP4A/ 71914CD/HCP4A 34.5 KN 34 KN 70 mm 0.28 kg 100 mm 16 mm
471 7205CD/HCP4A/ 7205CD/HCP4A 13.5 KN 7.2 KN 25 mm 0.11 kg 52 mm 15 mm
472 7005CE/HCP4A/ 7005CE/HCP4A 8.32 KN 4.15 KN 25 mm 0.065 kg 47 mm 12 mm
473 7005ACE/P4AHU/ 7005ACE/P4AHU 7.93 KN 3.9 KN 25 mm 0.074 kg 47 mm 12 mm
474 71906CE/HCP4A/ 71906CE/HCP4A 5.59 KN 3.25 KN 30 mm 0.045 kg 47 mm 9 mm
475 71916CE/HCP4A/ 71916CE/HCP4A 22.5 KN 18 KN 80 mm 0.31 kg 110 mm 16 mm
476 7006ACE/HCP4A/ 7006ACE/HCP4A 8.84 KN 5 KN 30 mm 0.1 kg 55 mm 13 mm
477 71906ACE/P4AHU/ 71906ACE/P4AHU 5.27 KN 3.1 KN 30 mm 0.05 kg 47 mm 9 mm
478 7203CD/HCP4A/ 7203CD/HCP4A 9.23 KN 4.15 KN 17 mm 0.054 kg 40 mm 12 mm
479 7038CD/HCP4A/ 7038CD/HCP4A 247 KN 305 KN 190 mm 8.05 kg 290 mm 46 mm
480 71924ACE/HCP4A/ 71924ACE/HCP4A 44.9 KN 38 KN 120 mm 0.93 kg 165 mm 22 mm
481 71907CE/HCP4A/ 71907CE/HCP4A 7.61 KN 4.75 KN 35 mm 0.067 kg 55 mm 10 mm
482 7006ACE/P4AHU/ 7006ACE/P4AHU 8.84 KN 5 KN 30 mm 0.11 kg 55 mm 13 mm
483 7218CD/HCP4A/ 7218CD/HCP4A 127 KN 112 KN 90 mm 1.85 kg 160 mm 30 mm
484 71918CE/HCP4A/ 71918CE/HCP4A 30.2 KN 24.5 KN 90 mm 0.46 kg 125 mm 18 mm
485 7016CE/HCP4A/ 7016CE/HCP4A 33.8 KN 28 KN 80 mm 0.77 kg 125 mm 22 mm
486 7213CD/HCP4A/ 7213CD/HCP4A 66.3 KN 53 KN 65 mm 0.88 kg 120 mm 23 mm
487 71907ACE/HCP4A/ 71907ACE/HCP4A 7.28 KN 4.5 KN 35 mm 0.067 kg 55 mm 10 mm
488 71921CD/HCP4A/ 71921CD/HCP4A 61.8 KN 69.5 KN 105 mm 0.7 kg 145 mm 20 mm
489 7021CD/HCP4A/ 7021CD/HCP4A 95.6 KN 96.5 KN 105 mm 1.3 kg 160 mm 26 mm
490 71917CE/HCP4A/ 71917CE/HCP4A 29.6 KN 23.2 KN 85 mm 0.42 kg 120 mm 18 mm
491 7015CD/HCP4A/ 7015CD/HCP4A 52.7 KN 49 KN 75 mm 0.53 kg 115 mm 20 mm
492 7013CD/HCP4A/ 7013CD/HCP4A 41.6 KN 37.5 KN 65 mm 0.36 kg 100 mm 18 mm
493 71904CD/HCP4A/ 71904CD/HCP4A 6.05 KN 3.2 KN 20 mm 0.033 kg 37 mm 9 mm
494 7007ACE/P4AHU/ 7007ACE/P4AHU 11.1 KN 6.3 KN 35 mm 0.15 kg 62 mm 14 mm
495 7014CD/HCP4A/ 7014CD/HCP4A 52 KN 45.5 KN 70 mm 0.5 kg 110 mm 20 mm
496 7024CE/HCP4A/ 7024CE/HCP4A 57.2 KN 55 KN 120 mm 1.95 kg 180 mm 28 mm
497 7214CD/HCP4A/ 7214CD/HCP4A 68.9 KN 58.5 KN 70 mm 0.95 kg 125 mm 24 mm
498 71915CD/HCP4A/ 71915CD/HCP4A 35.8 KN 37.5 KN 75 mm 0.3 kg 105 mm 16 mm
499 7003CE/HCP4A/ 7003CE/HCP4A 5.85 KN 2.55 KN 17 mm 0.030 kg 35 mm 10 mm
500 7008ACE/P4AHU/ 7008ACE/P4AHU 11.7 KN 7.2 KN 40 mm 0.19 kg 68 mm 15 mm
