Spindellager

Das Bild kann vom Produkt abweichen. Weitere Informationen finden Sie in den technischen Daten.

Spindellager

Spindellager sind kritische Komponenten in Werkzeugmaschinen, Industrierobotern und schnell rotierenden Anlagen, die in erster Linie zur Lagerung und Führung der Spindelrotation dienen. Zu den gängigen Typen zählen Schrägkugellager, Zylinderrollenlager und Hybridkeramiklager, die sich durch hohe Präzision, hohe Steifigkeit und geringe Reibung auszeichnen. Sie erfüllen die Anforderungen an hohe Drehzahlen, hohe Belastungen und hervorragende Stabilität und spielen eine entscheidende Rolle in der Präzisionsbearbeitung, Luft- und Raumfahrt sowie in der Automatisierungsindustrie.

Standard

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh,DIN / VDEh

Innenringdurchmesser

10mm-280mm

Außenringdurchmesser

20mm-400mm

Gewicht

0.2kg-300kg

Material

GCr15, 52100, 100Cr6, SUJ2, Edelstahl, deutscher hochstickstoffhaltiger Edelstahl CRONIDUR30, Keramik

Marke

QIBR/OEM/Neutral

Anwendungen

Werkzeugmaschinenspindel, Zentrifuge, Druckerhöhungspumpe, Ölpumpe, Gebläse, verschiedene Getriebe, Laborgeräte

Verpackung

QIBR/Standard-Industrieverpackung/OEM

Paarungsmethode

DB, DF, DT, DBD, DBB, SU

Spindellager

Filter

Nr. Produkt Produktnummer Dynamische Tragzahl Statische Tragzahl Innendurchmesser (d) Masse Außendurchmesser (D) Breite (B)
8401 HCB7207-E-T-P4S/ HCB7207-E-T-P4S 17.60 KN 8.80 KN 35 mm 0.24 kg 72 mm 17 mm
8402 HCB7207-C-DLR-T-P4S/ HCB7207-C-DLR-T-P4S 17.60 KN 8.80 KN 35 mm 0.24 kg 72 mm 17 mm
8403 HCB7207-E-P4S-U/ HCB7207-E-P4S-U 17.60 KN 8.80 KN 35 mm 0.24 kg 72 mm 17 mm
8404 HCB7207-C-P2-DT-L/ HCB7207-C-P2-DT-L 16.60 KN 8.50 KN 35 mm 0.24 kg 72 mm 17 mm
8405 HCB7207-E-P2-DB/ HCB7207-E-P2-DB 16.60 KN 8.50 KN 35 mm 0.24 kg 72 mm 17 mm
8406 B71808-E-TPA-P4/ B71808-E-TPA-P4 4.80 KN 4.55 KN 40 mm 0.03 kg 52 mm 7 mm
8407 B71808-C-TPA-P4/ B71808-C-TPA-P4 4.80 KN 4.55 KN 40 mm 0.03 kg 52 mm 7 mm
8408 B71808-C-P2-DB/ B71808-C-P2-DB 4.80 KN 4.55 KN 40 mm 0.03 kg 52 mm 7 mm
8409 B71808-CDLR-TX-P2/ B71808-CDLR-TX-P2 4.80 KN 4.55 KN 40 mm 0.03 kg 52 mm 7 mm
8410 B71808-EDLR-TX-P2/ B71808-EDLR-TX-P2 4.80 KN 4.55 KN 40 mm 0.03 kg 52 mm 7 mm
8411 B71808-E-P4-U/ B71808-E-P4-U 4.80 KN 4.55 KN 40 mm 0.03 kg 52 mm 7 mm
8412 B71808-E-P4-U/ B71808-E-P4-U 4.80 KN 4.55 KN 40 mm 0.03 kg 52 mm 7 mm
8413 B71808-E-P2-DB-L/ B71808-E-P2-DB-L 4.55 KN 4.25 KN 40 mm 0.03 kg 52 mm 7 mm
8414 B71808-E-P2-DT/ B71808-E-P2-DT 4.55 KN 4.25 KN 40 mm 0.03 kg 52 mm 7 mm
8415 HCB71808-EDLR-TPA-P4/ HCB71808-EDLR-TPA-P4 3.35 KN 3.15 KN 40 mm 0.03 kg 52 mm 7 mm
8416 HCB71808-C-TPA-P4/ HCB71808-C-TPA-P4 3.35 KN 3.15 KN 40 mm 0.03 kg 52 mm 7 mm
8417 HCB71808-E-TPA-P4/ HCB71808-E-TPA-P4 3.35 KN 3.15 KN 40 mm 0.03 kg 52 mm 7 mm
8418 B71908-C-T-P4S/ B71908-C-T-P4S 17.60 KN 13.70 KN 40 mm 0.11 kg 62 mm 12 mm
8419 B71908-E-T-P4S/ B71908-E-T-P4S 17.60 KN 13.70 KN 40 mm 0.11 kg 62 mm 12 mm
8420 B71908-C-P2-DB/ B71908-C-P2-DB 17.60 KN 13.70 KN 40 mm 0.11 kg 62 mm 12 mm
8421 B71908-E-P2-DB-L/ B71908-E-P2-DB-L 17.60 KN 13.70 KN 40 mm 0.11 kg 62 mm 12 mm
8422 B71908-E-P2-DT/ B71908-E-P2-DT 17.60 KN 13.70 KN 40 mm 0.11 kg 62 mm 12 mm
8423 71908 71908 ACE/HCP2 9.23 KN 5.85 KN 40 mm 0.1 kg 62 mm 12 mm
8424 HCB71808-C-P2-DT-L/ HCB71808-C-P2-DT-L 3.15 KN 2.90 KN 40 mm 0.03 kg 52 mm 7 mm
8425 HCB71808-E-P2-DB/ HCB71808-E-P2-DB 3.15 KN 2.90 KN 40 mm 0.03 kg 52 mm 7 mm
8426 B71908-CDLR-T-P4S/ B71908-CDLR-T-P4S 17.60 KN 13.70 KN 40 mm 0.11 kg 62 mm 12 mm
8427 B71908-EDLR-T-P4S/ B71908-EDLR-T-P4S 17.60 KN 13.70 KN 40 mm 0.11 kg 62 mm 12 mm
8428 B71908-CDLR-TX-P2/ B71908-CDLR-TX-P2 17.60 KN 13.70 KN 40 mm 0.11 kg 62 mm 12 mm
8429 HC71908-CDLR-T-P4S/ HC71908-CDLR-T-P4S 17.60 KN 13.70 KN 40 mm 0.11 kg 62 mm 12 mm
8430 B71908-EDLR-TX-P2/ B71908-EDLR-TX-P2 17.60 KN 13.70 KN 40 mm 0.11 kg 62 mm 12 mm
8431 B71908-C-P4S-U/ B71908-C-P4S-U 17.60 KN 13.70 KN 40 mm 0.11 kg 62 mm 12 mm
8432 B71908-C-P4S-DF/ B71908-C-P4S-DF 17.60 KN 13.70 KN 40 mm 0.11 kg 62 mm 12 mm
8433 B71908-E-P4S-U/ B71908-E-P4S-U 17.60 KN 13.70 KN 40 mm 0.11 kg 62 mm 12 mm
8434 B71908-E-P4S-DF/ B71908-E-P4S-DF 17.60 KN 13.70 KN 40 mm 0.11 kg 62 mm 12 mm
8435 B71908-C-P4S-DB/ B71908-C-P4S-DB 17.60 KN 13.70 KN 40 mm 0.11 kg 62 mm 12 mm
8436 HCB71908-EDLR-T-P4S/ HCB71908-EDLR-T-P4S 12.20 KN 9.65 KN 40 mm 0.09 kg 62 mm 12 mm
8437 HCB71908-C-P4S-U/ HCB71908-C-P4S-U 12.20 KN 9.65 KN 40 mm 0.09 kg 62 mm 12 mm
8438 HCB71908-E-T-P4S/ HCB71908-E-T-P4S 12.20 KN 9.65 KN 40 mm 0.09 kg 62 mm 12 mm
8439 HCB71908-C-T-P4S/ HCB71908-C-T-P4S 12.20 KN 9.65 KN 40 mm 0.09 kg 62 mm 12 mm
8440 HCB71908-C-DLR-T-P4S/ HCB71908-C-DLR-T-P4S 12.20 KN 9.65 KN 40 mm 0.09 kg 62 mm 12 mm
8441 HCB71908-E-P4S-U/ HCB71908-E-P4S-U 12.20 KN 9.65 KN 40 mm 0.09 kg 62 mm 12 mm
8442 HCB71908-E-P2-DB/ HCB71908-E-P2-DB 11.40 KN 9.15 KN 40 mm 0.09 kg 62 mm 12 mm
8443 HCB71908-C-P2-DT-L/ HCB71908-C-P2-DT-L 11.40 KN 9.15 KN 40 mm 0.09 kg 62 mm 12 mm
8444 XC71908-C-P2-DB-M/ XC71908-C-P2-DB-M 27.00 KN 9.65 KN 40 mm 0.09 kg 62 mm 12 mm
8445 XCB71908-C-P2-DT/ XCB71908-C-P2-DT 27.00 KN 9.65 KN 40 mm 0.09 kg 62 mm 12 mm
8446 XCB71908-E-P2-DT-M/ XCB71908-E-P2-DT-M 27.00 KN 9.65 KN 40 mm 0.09 kg 62 mm 12 mm
8447 XC71908-C-P2-DT/ XC71908-C-P2-DT 27.00 KN 9.65 KN 40 mm 0.09 kg 62 mm 12 mm
8448 XC71908-C-P2-H/ XC71908-C-P2-H 27.00 KN 9.65 KN 40 mm 0.09 kg 62 mm 12 mm
8449 XC71908-E-P2-DT-M/ XC71908-E-P2-DT-M 27.00 KN 9.65 KN 40 mm 0.09 kg 62 mm 12 mm
8450 XCB71908-C-P2-DB-M/ XCB71908-C-P2-DB-M 27.00 KN 9.65 KN 40 mm 0.09 kg 62 mm 12 mm
8451 XCB71908-C-T-P4S/ XCB71908-C-T-P4S 27.00 KN 9.65 KN 40 mm 0.09 kg 62 mm 12 mm
8452 XCB71908-CDLR-T-P4S/ XCB71908-CDLR-T-P4S 27.00 KN 9.65 KN 40 mm 0.09 kg 62 mm 12 mm
8453 XCB71908-C-P4S-U/ XCB71908-C-P4S-U 27.00 KN 9.65 KN 40 mm 0.09 kg 62 mm 12 mm
8454 XCB71908-C-P4S-DB/ XCB71908-C-P4S-DB 27.00 KN 9.65 KN 40 mm 0.09 kg 62 mm 12 mm
8455 XCB71908-C-P4S-DF/ XCB71908-C-P4S-DF 27.00 KN 9.65 KN 40 mm 0.09 kg 62 mm 12 mm
8456 XCB71908-E-P4S-DF/ XCB71908-E-P4S-DF 27.00 KN 9.65 KN 40 mm 0.09 kg 62 mm 12 mm
8457 XCB71908-E-P2-DB/ XCB71908-E-P2-DB 25.50 KN 9.15 KN 40 mm 0.09 kg 62 mm 12 mm
8458 XCB71908-E-T-P4S/ XCB71908-E-T-P4S 25.50 KN 9.15 KN 40 mm 0.09 kg 62 mm 12 mm
8459 XCB71908-EDLR-T-P4S/ XCB71908-EDLR-T-P4S 25.50 KN 9.15 KN 40 mm 0.09 kg 62 mm 12 mm
8460 XCB71908-EDLR-TX-P2/ XCB71908-EDLR-TX-P2 25.50 KN 9.15 KN 40 mm 0.09 kg 62 mm 12 mm
8461 XCB71908-E-P4S-U/ XCB71908-E-P4S-U 25.50 KN 9.15 KN 40 mm 0.09 kg 62 mm 12 mm
8462 XCB71908-E-P4S-DB/ XCB71908-E-P4S-DB 25.50 KN 9.15 KN 40 mm 0.09 kg 62 mm 12 mm
8463 HS71908-C-P2-DB-H/ HS71908-C-P2-DB-H 7.20 KN 6.95 KN 40 mm 0.13 kg 62 mm 12 mm
8464 HS71908-C-T-P4S/ HS71908-C-T-P4S 7.20 KN 6.95 KN 40 mm 0.13 kg 62 mm 12 mm
8465 HS71908-C-DLR-T-P4S/ HS71908-C-DLR-T-P4S 7.20 KN 6.95 KN 40 mm 0.13 kg 62 mm 12 mm
8466 HS71908-C-T-P4S-DF/ HS71908-C-T-P4S-DF 7.20 KN 6.95 KN 40 mm 0.13 kg 62 mm 12 mm
8467 HS71908-E-T-P4S-DF/ HS71908-E-T-P4S-DF 7.20 KN 6.95 KN 40 mm 0.13 kg 62 mm 12 mm
8468 B7008-C-T-P4S/ B7008-C-T-P4S 20.40 KN 16.00 KN 40 mm 0.19 kg 68 mm 15 mm
8469 B7008-E-P2-DB-L/ B7008-E-P2-DB-L 20.40 KN 16.00 KN 40 mm 0.19 kg 68 mm 15 mm
8470 B7008-E-T-P4S/ B7008-E-T-P4S 20.40 KN 16.00 KN 40 mm 0.19 kg 68 mm 15 mm
8471 B7008-C-P2-DB/ B7008-C-P2-DB 20.40 KN 16.00 KN 40 mm 0.19 kg 68 mm 15 mm
8472 B7008-E-P2-DT/ B7008-E-P2-DT 20.40 KN 16.00 KN 40 mm 0.19 kg 68 mm 15 mm
8473 7008ACE/P2H1DF/ 7008ACE/P2H1DF 11.70 KN 7.20 KN 40 mm 0.19 kg 68 mm 15 mm
8474 7008ACE/HCP2/ 7008ACE/HCP2 11.70 KN 7.20 KN 40 mm 0.19 kg 68 mm 15 mm
8475 HC7008-CDLR-T-P4S/ HC7008-CDLR-T-P4S 20.40 KN 16.00 KN 40 mm 0.19 kg 68 mm 15 mm
8476 B7008-EDLR-T-P4S/ B7008-EDLR-T-P4S 20.40 KN 16.00 KN 40 mm 0.19 kg 68 mm 15 mm
8477 B7008-CDLR-T-P4S/ B7008-CDLR-T-P4S 20.40 KN 16.00 KN 40 mm 0.19 kg 68 mm 15 mm
8478 B7008 B7008 C 12.9 KN 7.4 KN 40 mm 0.19 kg 68 mm 15 mm
8479 B7008-CDLR-TX-P2/ B7008-CDLR-TX-P2 20.40 KN 16.00 KN 40 mm 0.19 kg 68 mm 15 mm
8480 B7008 B7008 C/HQ1 12.9 KN 7.4 KN 40 mm 0.19 kg 68 mm 15 mm
8481 B7008-EDLR-TX-P2/ B7008-EDLR-TX-P2 20.40 KN 16.00 KN 40 mm 0.19 kg 68 mm 15 mm
8482 B7008-C-P4S-U/ B7008-C-P4S-U 20.40 KN 16.00 KN 40 mm 0.19 kg 68 mm 15 mm
8483 B7008-E-P4S-U/ B7008-E-P4S-U 20.40 KN 16.00 KN 40 mm 0.19 kg 68 mm 15 mm
8484 B7008-E-P4S-DF/ B7008-E-P4S-DF 20.40 KN 16.00 KN 40 mm 0.19 kg 68 mm 15 mm
8485 B7008-C-P4S-DB/ B7008-C-P4S-DB 20.40 KN 16.00 KN 40 mm 0.19 kg 68 mm 15 mm
8486 HCB7008-EDLR-T-P4S/ HCB7008-EDLR-T-P4S 14.30 KN 11.00 KN 40 mm 0.17 kg 68 mm 15 mm
8487 HCB7008-C-P4S-U/ HCB7008-C-P4S-U 14.30 KN 11.00 KN 40 mm 0.17 kg 68 mm 15 mm
8488 HCB7008-C-T-P4S/ HCB7008-C-T-P4S 14.30 KN 11.00 KN 40 mm 0.17 kg 68 mm 15 mm
8489 HCB7008-E-T-P4S/ HCB7008-E-T-P4S 14.30 KN 11.00 KN 40 mm 0.17 kg 68 mm 15 mm
8490 HCB7008-C-DLR-T-P4S/ HCB7008-C-DLR-T-P4S 14.30 KN 11.00 KN 40 mm 0.17 kg 68 mm 15 mm
8491 HCB7008-E-P4S-U/ HCB7008-E-P4S-U 14.30 KN 11.00 KN 40 mm 0.17 kg 68 mm 15 mm
8492 HCB7008-C-P2-DT-L/ HCB7008-C-P2-DT-L 13.40 KN 10.60 KN 40 mm 0.17 kg 68 mm 15 mm
8493 HCB7008-E-P2-DB/ HCB7008-E-P2-DB 13.40 KN 10.60 KN 40 mm 0.17 kg 68 mm 15 mm
8494 XCB7008-C-P2-DB-M/ XCB7008-C-P2-DB-M 32.00 KN 11.00 KN 40 mm 0.17 kg 68 mm 15 mm
8495 XC7008-C-P2-DB-M/ XC7008-C-P2-DB-M 32.00 KN 11.00 KN 40 mm 0.17 kg 68 mm 15 mm
8496 XCB7008-C-P2-DT/ XCB7008-C-P2-DT 32.00 KN 11.00 KN 40 mm 0.17 kg 68 mm 15 mm
8497 XC7008-C-P2-DT/ XC7008-C-P2-DT 32.00 KN 11.00 KN 40 mm 0.17 kg 68 mm 15 mm
8498 XCB7008-E-P2-DT-M/ XCB7008-E-P2-DT-M 32.00 KN 11.00 KN 40 mm 0.17 kg 68 mm 15 mm
8499 XC7008-C-P2-H/ XC7008-C-P2-H 32.00 KN 11.00 KN 40 mm 0.17 kg 68 mm 15 mm
8500 XC7008-E-P2-DT-M/ XC7008-E-P2-DT-M 32.00 KN 11.00 KN 40 mm 0.17 kg 68 mm 15 mm
