Spindellager

Das Bild kann vom Produkt abweichen. Weitere Informationen finden Sie in den technischen Daten.

Spindellager

Spindellager sind kritische Komponenten in Werkzeugmaschinen, Industrierobotern und schnell rotierenden Anlagen, die in erster Linie zur Lagerung und Führung der Spindelrotation dienen. Zu den gängigen Typen zählen Schrägkugellager, Zylinderrollenlager und Hybridkeramiklager, die sich durch hohe Präzision, hohe Steifigkeit und geringe Reibung auszeichnen. Sie erfüllen die Anforderungen an hohe Drehzahlen, hohe Belastungen und hervorragende Stabilität und spielen eine entscheidende Rolle in der Präzisionsbearbeitung, Luft- und Raumfahrt sowie in der Automatisierungsindustrie.

Standard

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh,DIN / VDEh

Innenringdurchmesser

10mm-280mm

Außenringdurchmesser

20mm-400mm

Gewicht

0.2kg-300kg

Material

GCr15, 52100, 100Cr6, SUJ2, Edelstahl, deutscher hochstickstoffhaltiger Edelstahl CRONIDUR30, Keramik

Marke

QIBR/OEM/Neutral

Anwendungen

Werkzeugmaschinenspindel, Zentrifuge, Druckerhöhungspumpe, Ölpumpe, Gebläse, verschiedene Getriebe, Laborgeräte

Verpackung

QIBR/Standard-Industrieverpackung/OEM

Paarungsmethode

DB, DF, DT, DBD, DBB, SU

Spindellager

Filter

Nr. Produkt Produktnummer Dynamische Tragzahl Statische Tragzahl Innendurchmesser (d) Masse Außendurchmesser (D) Breite (B)
7101 7202CD/GAP2H1/ 7202CD/GAP2H1 7.41 KN 3.35 KN 15 mm 0.043 kg 35 mm 11 mm
7102 7203CD/GAP2H1/ 7203CD/GAP2H1 9.23 KN 4.15 KN 17 mm 0.063 kg 40 mm 12 mm
7103 7205CD/GAP2H1/ 7205CD/GAP2H1 13.5 KN 7.2 KN 25 mm 0.13 kg 52 mm 15 mm
7104 7207CD/GAP2H1/ 7207CD/GAP2H1 31.9 KN 21.6 KN 35 mm 0.29 kg 72 mm 17 mm
7105 7208CD/GAP2H1/ 7208CD/GAP2H1 33.8 KN 24 KN 40 mm 0.37 kg 80 mm 18 mm
7106 7209CD/GAP2H1/ 7209CD/GAP2H1 42.3 KN 31 KN 45 mm 0.41 kg 85 mm 19 mm
7107 7211CD/GAP2H1/ 7211CD/GAP2H1 55.3 KN 43 KN 55 mm 0.61 kg 100 mm 21 mm
7108 7215CD/GAP2H1/ 7215CD/GAP2H1 71.5 KN 62 KN 75 mm 1.2 kg 130 mm 25 mm
7109 7216CD/GAP2H1/ 7216CD/GAP2H1 85.2 KN 75 KN 80 mm 1.45 kg 140 mm 26 mm
7110 7219CD/GAP2H1/ 7219CD/GAP2H1 138 KN 120 KN 95 mm 2.7 kg 170 mm 32 mm
7111 7220CD/GAP2H1/ 7220CD/GAP2H1 156 KN 137 KN 100 mm 3.25 kg 180 mm 34 mm
7112 7221CD/GAP2H1/ 7221CD/GAP2H1 172 KN 153 KN 105 mm 3.85 kg 190 mm 36 mm
7113 727CD/GAP2H1/ 727CD/GAP2H1 2.96 KN 1.16 KN 7 mm 0.013 kg 22 mm 7 mm
7114 7905A5TYNDBLP4/ 7905A5TYNDBLP4 7.45 KN 5.15 KN 25 mm 0.043 kg 42 mm 9 mm
7115 7905A5TRDB/ 7905A5TRDB 7.45 KN 5.15 KN 25 mm 0.043 kg 42 mm 9 mm
7116 B709-C-P2-DB/ B709-C-P2-DB 5.20 KN 2.40 KN 9 mm 0.015 kg 24 mm 7 mm
7117 HC709-CDLR-T-P4S/ HC709-CDLR-T-P4S 5.20 KN 2.40 KN 9 mm 0.015 kg 24 mm 7 mm
7118 B709-E-T-P4S/ B709-E-T-P4S 5.20 KN 2.40 KN 9 mm 0.015 kg 24 mm 7 mm
7119 B709-C-T-P4S/ B709-C-T-P4S 5.20 KN 2.40 KN 9 mm 0.015 kg 24 mm 7 mm
7120 B709-CDLR-TX-P2/ B709-CDLR-TX-P2 5.20 KN 2.40 KN 9 mm 0.015 kg 24 mm 7 mm
7121 B709-EDLR-T-P4S/ B709-EDLR-T-P4S 5.20 KN 2.40 KN 9 mm 0.015 kg 24 mm 7 mm
7122 B709-CDLR-T-P4S/ B709-CDLR-T-P4S 5.20 KN 2.40 KN 9 mm 0.015 kg 24 mm 7 mm
7123 B709-EDLR-TX-P2/ B709-EDLR-TX-P2 5.20 KN 2.40 KN 9 mm 0.015 kg 24 mm 7 mm
7124 B709-C-P4S-U/ B709-C-P4S-U 5.20 KN 2.40 KN 9 mm 0.015 kg 24 mm 7 mm
7125 B709-C-P4S-DF/ B709-C-P4S-DF 5.20 KN 2.40 KN 9 mm 0.015 kg 24 mm 7 mm
7126 B709-E-P4S-U/ B709-E-P4S-U 5.20 KN 2.40 KN 9 mm 0.015 kg 24 mm 7 mm
7127 B709-C-P4S-DB/ B709-C-P4S-DB 5.20 KN 2.40 KN 9 mm 0.015 kg 24 mm 7 mm
7128 B709-E-P4S-DF/ B709-E-P4S-DF 5.20 KN 2.40 KN 9 mm 0.015 kg 24 mm 7 mm
7129 B709-E-P2-DT/ B709-E-P2-DT 5.10 KN 2.32 KN 9 mm 0.015 kg 24 mm 7 mm
7130 B709-E-P2-DB-L/ B709-E-P2-DB-L 5.10 KN 2.32 KN 9 mm 0.015 kg 24 mm 7 mm
7131 709 709 ACE/HCP2 2.15 KN 0.90 KN 9 mm 0.014kg 24 mm 7 mm
7132 HCB709-C-P2-DT-L/ HCB709-C-P2-DT-L 3.45 KN 1.60 KN 9 mm 0.013 kg 24 mm 7 mm
7133 HCB709-EDLR-T-P4S/ HCB709-EDLR-T-P4S 3.45 KN 1.60 KN 9 mm 0.013 kg 24 mm 7 mm
7134 HCB709-E-P2-DB/ HCB709-E-P2-DB 3.45 KN 1.60 KN 9 mm 0.013 kg 24 mm 7 mm
7135 HCB709-E-T-P4S/ HCB709-E-T-P4S 3.45 KN 1.60 KN 9 mm 0.013 kg 24 mm 7 mm
7136 HCB709-C-T-P4S/ HCB709-C-T-P4S 3.45 KN 1.60 KN 9 mm 0.013 kg 24 mm 7 mm
7137 HCB709-C-P4S-U/ HCB709-C-P4S-U 3.45 KN 1.60 KN 9 mm 0.013 kg 24 mm 7 mm
7138 HCB709-C-DLR-T-P4S/ HCB709-C-DLR-T-P4S 3.45 KN 1.60 KN 9 mm 0.013 kg 24 mm 7 mm
7139 HCB709-E-P4S-U/ HCB709-E-P4S-U 3.45 KN 1.60 KN 9 mm 0.013 kg 24 mm 7 mm
7140 7904CLP2/ 7904CLP2 7400 N 5800 N 20 mm 20 g 37 mm 9 mm
7141 7904CL/ 7904CL 7400 N 5800 N 20 mm 20 g 37 mm 9 mm
7142 7904CTYN/ 7904CTYN 7400 N 5800 N 20 mm 20 g 37 mm 9 mm
7143 XC709-C-P2-DB-M/ XC709-C-P2-DB-M 8.00 KN 1.66 KN 9 mm 0.013 kg 24 mm 7 mm
7144 XCB709-C-P2-DT/ XCB709-C-P2-DT 8.00 KN 1.66 KN 9 mm 0.013 kg 24 mm 7 mm
7145 XCB709-E-P2-DT-M/ XCB709-E-P2-DT-M 8.00 KN 1.66 KN 9 mm 0.013 kg 24 mm 7 mm
7146 XC709-C-P2-DT/ XC709-C-P2-DT 8.00 KN 1.66 KN 9 mm 0.013 kg 24 mm 7 mm
7147 XC709-C-P2-H/ XC709-C-P2-H 8.00 KN 1.66 KN 9 mm 0.013 kg 24 mm 7 mm
7148 XC709-E-P2-DT-M/ XC709-E-P2-DT-M 8.00 KN 1.66 KN 9 mm 0.013 kg 24 mm 7 mm
7149 XCB709-C-P2-DB-M/ XCB709-C-P2-DB-M 8.00 KN 1.66 KN 9 mm 0.013 kg 24 mm 7 mm
7150 XC709-C-T-P4S/ XC709-C-T-P4S 4.05 KN 1.00 KN 9 mm 0.013 kg 24 mm 7 mm
7151 XC709-E-T-P4S/ XC709-E-T-P4S 3.9 KN 0.95 KN 9 mm 0.013 kg 24 mm 7 mm
7152 XC709-E-P4S-DF/ XC709-E-P4S-DF 4.05 KN 1.00 KN 9 mm 0.013 kg 24 mm 7 mm
7153 XC709-EDLR-T-P4S/ XC709-EDLR-T-P4S 3.9 KN 0.95 KN 9 mm 0.013 kg 24 mm 7 mm
7154 XC709-CDLR-T-P4S/ XC709-CDLR-T-P4S 4.05 KN 1.00 KN 9 mm 0.013 kg 24 mm 7 mm
7155 XC709-C-P4S-DF/ XC709-C-P4S-DF 4.05 KN 1.00 KN 9 mm 0.013 kg 24 mm 7 mm
7156 XC709-EDLR-TX-P2/ XC709-EDLR-TX-P2 3.9 KN 0.95 KN 9 mm 0.013 kg 24 mm 7 mm
7157 XC709-CDLR-TX-P2/ XC709-CDLR-TX-P2 4.05 KN 1.00 KN 9 mm 0.013 kg 24 mm 7 mm
7158 XC709-C-P4S-U/ XC709-C-P4S-U 4.05 KN 1.00 KN 9 mm 0.013 kg 24 mm 7 mm
7159 XC709-E-P4S-U/ XC709-E-P4S-U 3.9 KN 0.95 KN 9 mm 0.013 kg 24 mm 7 mm
7160 XC709-E-P4S-DB/ XC709-E-P4S-DB 4.05 KN 1.00 KN 9 mm 0.013 kg 24 mm 7 mm
7161 XC709-C-P4S-DB/ XC709-C-P4S-DB 4.05 KN 1.00 KN 9 mm 0.013 kg 24 mm 7 mm
7162 7004CLP2/ 7004CLP2 1170 N 6550 N 20 mm 71 g 42 mm 12 mm
7163 XCB709-E-P2-DB/ XCB709-E-P2-DB 7.65 KN 1.60 KN 9 mm 0.013 kg 24 mm 7 mm
7164 XCB709-E-T-P4S/ XCB709-E-T-P4S 7.65 KN 1.60 KN 9 mm 0.013 kg 24 mm 7 mm
7165 XCB709-C-T-P4S/ XCB709-C-T-P4S 7.65 KN 1.60 KN 9 mm 0.013 kg 24 mm 7 mm
7166 XCB709-EDLR-T-P4S/ XCB709-EDLR-T-P4S 7.65 KN 1.60 KN 9 mm 0.013 kg 24 mm 7 mm
7167 XCB709-CDLR-T-P4S/ XCB709-CDLR-T-P4S 7.65 KN 1.60 KN 9 mm 0.013 kg 24 mm 7 mm
7168 XCB709-E-P4S-U/ XCB709-E-P4S-U 7.65 KN 1.60 KN 9 mm 0.013 kg 24 mm 7 mm
7169 XCB709-C-P4S-U/ XCB709-C-P4S-U 7.65 KN 1.60 KN 9 mm 0.013 kg 24 mm 7 mm
7170 XCB709-C-P4S-DB/ XCB709-C-P4S-DB 7.65 KN 1.60 KN 9 mm 0.013 kg 24 mm 7 mm
7171 XCB709-C-P4S-DF/ XCB709-C-P4S-DF 7.65 KN 1.60 KN 9 mm 0.013 kg 24 mm 7 mm
7172 XCB709-E-P4S-DB/ XCB709-E-P4S-DB 7.65 KN 1.60 KN 9 mm 0.013 kg 24 mm 7 mm
7173 HS709-C-P2-DB-H/ HS709-C-P2-DB-H 2.65 KN 1.43 KN 9 mm 0.020 kg 24 mm 7 mm
7174 HS709-C-T-P4S/ HS709-C-T-P4S 2.65 KN 1.43 KN 9 mm 0.020 kg 24 mm 7 mm
7175 HS709-E-T-P4S/ HS709-E-T-P4S 2.50 KN 1.37 KN 9 mm 0.020 kg 24 mm 7 mm
7176 HS709-EDLR-T-P4S/ HS709-EDLR-T-P4S 2.50 KN 1.37 KN 9 mm 0.020 kg 24 mm 7 mm
7177 HS709-C-DLR-T-P4S/ HS709-C-DLR-T-P4S 2.65 KN 1.43 KN 9 mm 0.020 kg 24 mm 7 mm
7178 HS709-C-P4S-U/ HS709-C-P4S-U 2.65 KN 1.43 KN 9 mm 0.020 kg 24 mm 7 mm
7179 HS709-E-P4S-U/ HS709-E-P4S-U 2.65 KN 1.43 KN 9 mm 0.020 kg 24 mm 7 mm
7180 HS709-C-P4S-DB/ HS709-C-P4S-DB 2.65 KN 1.43 KN 9 mm 0.020 kg 24 mm 7 mm
7181 HS709-E-T-P4S-DF/ HS709-E-T-P4S-DF 2.65 KN 1.43 KN 9 mm 0.020 kg 24 mm 7 mm
7182 HS709-C-T-P4S-DF/ HS709-C-T-P4S-DF 2.65 KN 1.43 KN 9 mm 0.020 kg 24 mm 7 mm
7183 HS709-E-P4S-DB/ HS709-E-P4S-DB 2.65 KN 1.43 KN 9 mm 0.020 kg 24 mm 7 mm
7184 7905CLP2/ 7905CLP2 8150 N 5700 N 25 mm 326 g 42 mm 9 mm
7185 7905CL/ 7905CL 8150 N 5700 N 25 mm 326 g 42 mm 9 mm
7186 7005CL/ 7005CL 1230 N 7400 N 25 mm 78 g 47 mm 12 mm
7187 7005CLP2/ 7005CLP2 1230 N 7400 N 25 mm 78 g 47 mm 12 mm
7188 B71800-C-P2-DB/ B71800-C-P2-DB 1.90 KN 0.98 KN 10 mm 0.005 kg 19 mm 5 mm
7189 B71800-CDLR-TX-P2/ B71800-CDLR-TX-P2 1.90 KN 0.98 KN 10 mm 0.005 kg 19 mm 5 mm
7190 B71800-EDLR-TX-P2/ B71800-EDLR-TX-P2 1.90 KN 0.98 KN 10 mm 0.005 kg 19 mm 5 mm
7191 B71800-E-P2-DB-L/ B71800-E-P2-DB-L 1.80 KN 0.93 KN 10 mm 0.005 kg 19 mm 5 mm
7192 B71800-E-P2-DT/ B71800-E-P2-DT 1.80 KN 0.93 KN 10 mm 0.005 kg 19 mm 5 mm
7193 B71800-E-TPA-P4/ B71800-E-TPA-P4 1.80 KN 0.93 KN 10 mm 0.005 kg 19 mm 5 mm
7194 B71800-C-TPA-P4/ B71800-C-TPA-P4 1.90 KN 0.98 KN 10 mm 0.005 kg 19 mm 5 mm
7195 B71800-E-P4-U/ B71800-E-P4-U 1.80 KN 0.93 KN 10 mm 0.005 kg 19 mm 5 mm
7196 7906CLP2/ 7906CLP2 8700 N 6250 N 30 mm 49 g 47 mm 9 mm
7197 7906CTYN/ 7906CTYN 8700 N 6250 N 30 mm 49 g 47 mm 9 mm
7198 7006CL/ 7006CL 13590 N 9890 N 30 mm 130 g 55 mm 13 mm
7199 7006CLP2/ 7006CLP2 13590 N 9890 N 30 mm 130 g 55 mm 13 mm
7200 HCB71800-EDLR-TPA-P4/ HCB71800-EDLR-TPA-P4 1.25 KN 0.65 KN 10 mm 0.005 kg 19 mm 5 mm
