Spindellager

Das Bild kann vom Produkt abweichen. Weitere Informationen finden Sie in den technischen Daten.

Spindellager

Spindellager sind kritische Komponenten in Werkzeugmaschinen, Industrierobotern und schnell rotierenden Anlagen, die in erster Linie zur Lagerung und Führung der Spindelrotation dienen. Zu den gängigen Typen zählen Schrägkugellager, Zylinderrollenlager und Hybridkeramiklager, die sich durch hohe Präzision, hohe Steifigkeit und geringe Reibung auszeichnen. Sie erfüllen die Anforderungen an hohe Drehzahlen, hohe Belastungen und hervorragende Stabilität und spielen eine entscheidende Rolle in der Präzisionsbearbeitung, Luft- und Raumfahrt sowie in der Automatisierungsindustrie.

Standard

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh,DIN / VDEh

Innenringdurchmesser

10mm-280mm

Außenringdurchmesser

20mm-400mm

Gewicht

0.2kg-300kg

Material

GCr15, 52100, 100Cr6, SUJ2, Edelstahl, deutscher hochstickstoffhaltiger Edelstahl CRONIDUR30, Keramik

Marke

QIBR/OEM/Neutral

Anwendungen

Werkzeugmaschinenspindel, Zentrifuge, Druckerhöhungspumpe, Ölpumpe, Gebläse, verschiedene Getriebe, Laborgeräte

Verpackung

QIBR/Standard-Industrieverpackung/OEM

Paarungsmethode

DB, DF, DT, DBD, DBB, SU

Spindellager

Filter

Nr. Produkt Produktnummer Dynamische Tragzahl Statische Tragzahl Innendurchmesser (d) Masse Außendurchmesser (D) Breite (B)
11001 B7232-CDLR-T-P4S/ B7232-CDLR-T-P4S 245.00 KN 285.00 KN 160 mm 13.0 kg 290 mm 48 mm
11002 B7232-CDLR-TX-P2/ B7232-CDLR-TX-P2 245.00 KN 285.00 KN 160 mm 13.0 kg 290 mm 48 mm
11003 B7232-EDLR-TX-P2/ B7232-EDLR-TX-P2 245.00 KN 285.00 KN 160 mm 13.0 kg 290 mm 48 mm
11004 B7232-C-P4S-U/ B7232-C-P4S-U 245.00 KN 285.00 KN 160 mm 13.0 kg 290 mm 48 mm
11005 B7232-C-P4S-DF/ B7232-C-P4S-DF 245.00 KN 285.00 KN 160 mm 13.0 kg 290 mm 48 mm
11006 B7232-E-P2-DT/ B7232-E-P2-DT 232.00 KN 270.00 KN 160 mm 13.0 kg 290 mm 48 mm
11007 B7232-E-P2-DB-L/ B7232-E-P2-DB-L 232.00 KN 270.00 KN 160 mm 13.0 kg 290 mm 48 mm
11008 B7232-EDLR-T-P4S/ B7232-EDLR-T-P4S 232.00 KN 270.00 KN 160 mm 13.0 kg 290 mm 48 mm
11009 B7232-E-T-P4S/ B7232-E-T-P4S 232.00 KN 270.00 KN 160 mm 13.0 kg 290 mm 48 mm
11010 B7232-E-P4S-U/ B7232-E-P4S-U 232.00 KN 270.00 KN 160 mm 13.0 kg 290 mm 48 mm
11011 B7232-E-P4S-DF/ B7232-E-P4S-DF 232.00 KN 270.00 KN 160 mm 13.0 kg 290 mm 48 mm
11012 HCB7232-C-T-P4S/ HCB7232-C-T-P4S 170.00 KN 200.00 KN 160 mm 11.6 kg 290 mm 48 mm
11013 HCB7232-C-DLR-T-P4S/ HCB7232-C-DLR-T-P4S 170.00 KN 200.00 KN 160 mm 11.6 kg 290 mm 48 mm
11014 HCB7232-C-P4S-U/ HCB7232-C-P4S-U 170.00 KN 200.00 KN 160 mm 11.6 kg 290 mm 48 mm
11015 HCB7232-E-T-P4S/ HCB7232-E-T-P4S 160.00 KN 190.00 KN 160 mm 11.6 kg 290 mm 48 mm
11016 HCB7232-E-P2-DB/ HCB7232-E-P2-DB 160.00 KN 190.00 KN 160 mm 11.6 kg 290 mm 48 mm
11017 HCB7232-C-P2-DT-L/ HCB7232-C-P2-DT-L 160.00 KN 190.00 KN 160 mm 11.6 kg 290 mm 48 mm
11018 HCB7232-EDLR-T-P4S/ HCB7232-EDLR-T-P4S 160.00 KN 190.00 KN 160 mm 11.6 kg 290 mm 48 mm
11019 HCB7232-E-P4S-U/ HCB7232-E-P4S-U 160.00 KN 190.00 KN 160 mm 11.6 kg 290 mm 48 mm
11020 B71834-C-P2-DB/ B71834-C-P2-DB 68.00 KN 88.00 KN 170 mm 1.6 kg 215 mm 22 mm
11021 B71834-C-TPA-P4/ B71834-C-TPA-P4 68.00 KN 88.00 KN 170 mm 1.6 kg 215 mm 22 mm
11022 B71834-CDLR-TX-P2/ B71834-CDLR-TX-P2 68.00 KN 88.00 KN 170 mm 1.6 kg 215 mm 22 mm
11023 B71834-EDLR-TX-P2/ B71834-EDLR-TX-P2 68.00 KN 88.00 KN 170 mm 1.6 kg 215 mm 22 mm
11024 B71834-E-P2-DT/ B71834-E-P2-DT 64.00 KN 81.50 KN 170 mm 1.6 kg 215 mm 22 mm
11025 B71834-E-P2-DB-L/ B71834-E-P2-DB-L 64.00 KN 81.50 KN 170 mm 1.6 kg 215 mm 22 mm
11026 B71834-E-TPA-P4/ B71834-E-TPA-P4 64.00 KN 81.50 KN 170 mm 1.6 kg 215 mm 22 mm
11027 B71834-E-P4-U/ B71834-E-P4-U 64.00 KN 81.50 KN 170 mm 1.6 kg 215 mm 22 mm
11028 HCB71834-C-TPA-P4/ HCB71834-C-TPA-P4 47.50 KN 61.00 KN 170 mm 1.6 kg 215 mm 22 mm
11029 HCB71834-E-P2-DB/ HCB71834-E-P2-DB 64.00 KN 81.50 KN 170 mm 1.6 kg 215 mm 22 mm
11030 HCB71834-C-P2-DT-L/ HCB71834-C-P2-DT-L 64.00 KN 81.50 KN 170 mm 1.6 kg 215 mm 22 mm
11031 HCB71834-E-TPA-P4/ HCB71834-E-TPA-P4 45.00 KN 57.00 KN 170 mm 1.6 kg 215 mm 22 mm
11032 HCB71834-EDLR-TPA-P4/ HCB71834-EDLR-TPA-P4 45.00 KN 57.00 KN 170 mm 1.6 kg 215 mm 22 mm
11033 HCB71834-E-P4-U/ HCB71834-E-P4-U 45.00 KN 57.00 KN 170 mm 1.6 kg 215 mm 22 mm
11034 B71934-C-P2-DB/ B71934-C-P2-DB 129.00 KN 163.00 KN 170 mm 2.8 kg 230 mm 28 mm
11035 B71934-C-T-P4S/ B71934-C-T-P4S 129.00 KN 163.00 KN 170 mm 2.8 kg 230 mm 28 mm
11036 B71934-CDLR-T-P4S/ B71934-CDLR-T-P4S 129.00 KN 163.00 KN 170 mm 2.8 kg 230 mm 28 mm
11037 B71934-CDLR-TX-P2/ B71934-CDLR-TX-P2 129.00 KN 163.00 KN 170 mm 2.8 kg 230 mm 28 mm
11038 B71934-EDLR-TX-P2/ B71934-EDLR-TX-P2 129.00 KN 163.00 KN 170 mm 2.8 kg 230 mm 28 mm
11039 B71934-C-P4S-U/ B71934-C-P4S-U 129.00 KN 163.00 KN 170 mm 2.8 kg 230 mm 28 mm
11040 B71934-C-P4S-DB/ B71934-C-P4S-DB 129.00 KN 163.00 KN 170 mm 2.8 kg 230 mm 28 mm
11041 B71934-C-P4S-DF/ B71934-C-P4S-DF 129.00 KN 163.00 KN 170 mm 2.8 kg 230 mm 28 mm
11042 B71934-E-P2-DT/ B71934-E-P2-DT 122.00 KN 150.00 KN 170 mm 2.8 kg 230 mm 28 mm
11043 B71934-E-P2-DB-L/ B71934-E-P2-DB-L 122.00 KN 150.00 KN 170 mm 2.8 kg 230 mm 28 mm
11044 B71934-EDLR-T-P4S/ B71934-EDLR-T-P4S 122.00 KN 150.00 KN 170 mm 2.8 kg 230 mm 28 mm
11045 B71934-E-T-P4S/ B71934-E-T-P4S 122.00 KN 150.00 KN 170 mm 2.8 kg 230 mm 28 mm
11046 B71934-E-P4S-U/ B71934-E-P4S-U 122.00 KN 150.00 KN 170 mm 2.8 kg 230 mm 28 mm
11047 B71934-E-P4S-DF/ B71934-E-P4S-DF 122.00 KN 150.00 KN 170 mm 2.8 kg 230 mm 28 mm
11048 HCB71934-C-T-P4S/ HCB71934-C-T-P4S 88.00 KN 114.00 KN 170 mm 2.4 kg 230 mm 28 mm
11049 HCB71934-C-DLR-T-P4S/ HCB71934-C-DLR-T-P4S 88.00 KN 114.00 KN 170 mm 2.4 kg 230 mm 28 mm
11050 HCB71934-C-P4S-U/ HCB71934-C-P4S-U 88.00 KN 114.00 KN 170 mm 2.4 kg 230 mm 28 mm
11051 HCB71934-E-P2-DB/ HCB71934-E-P2-DB 83.00 KN 106.00 KN 170 mm 2.4 kg 230 mm 28 mm
11052 HCB71934-C-P2-DT-L/ HCB71934-C-P2-DT-L 83.00 KN 106.00 KN 170 mm 2.4 kg 230 mm 28 mm
11053 HCB71934-E-T-P4S/ HCB71934-E-T-P4S 83.00 KN 106.00 KN 170 mm 2.4 kg 230 mm 28 mm
11054 HCB71934-EDLR-T-P4S/ HCB71934-EDLR-T-P4S 83.00 KN 106.00 KN 170 mm 2.4 kg 230 mm 28 mm
11055 HCB71934-E-P4S-U/ HCB71934-E-P4S-U 83.00 KN 106.00 KN 170 mm 2.4 kg 230 mm 28 mm
11056 B7034-C-P2-DB/ B7034-C-P2-DB 236.00 KN 270.00 KN 170 mm 6.7 kg 260 mm 42 mm
11057 B7034-C-T-P4S/ B7034-C-T-P4S 236.00 KN 270.00 KN 170 mm 6.7 kg 260 mm 42 mm
11058 B7034-CDLR-T-P4S/ B7034-CDLR-T-P4S 236.00 KN 270.00 KN 170 mm 6.7 kg 260 mm 42 mm
11059 B7034-CDLR-TX-P2/ B7034-CDLR-TX-P2 236.00 KN 270.00 KN 170 mm 6.7 kg 260 mm 42 mm
11060 B7034-EDLR-TX-P2/ B7034-EDLR-TX-P2 236.00 KN 270.00 KN 170 mm 6.7 kg 260 mm 42 mm
11061 B7034-C-P4S-U/ B7034-C-P4S-U 236.00 KN 270.00 KN 170 mm 6.7 kg 260 mm 42 mm
11062 B7034-C-P4S-DF/ B7034-C-P4S-DF 236.00 KN 270.00 KN 170 mm 6.7 kg 260 mm 42 mm
11063 B7034-E-P2-DT/ B7034-E-P2-DT 224.00 KN 255.00 KN 170 mm 6.7 kg 260 mm 42 mm
11064 B7034-E-P2-DB-L/ B7034-E-P2-DB-L 224.00 KN 255.00 KN 170 mm 6.7 kg 260 mm 42 mm
11065 B7034-EDLR-T-P4S/ B7034-EDLR-T-P4S 224.00 KN 255.00 KN 170 mm 6.7 kg 260 mm 42 mm
11066 B7034-E-T-P4S/ B7034-E-T-P4S 224.00 KN 255.00 KN 170 mm 6.7 kg 260 mm 42 mm
11067 B7034-E-P4S-U/ B7034-E-P4S-U 224.00 KN 255.00 KN 170 mm 6.7 kg 260 mm 42 mm
11068 B7234-C-P2-DB/ B7234-C-P2-DB 300.00 KN 360.00 KN 170 mm 16.0 kg 310 mm 52 mm
11069 B7234-C-T-P4S/ B7234-C-T-P4S 300.00 KN 360.00 KN 170 mm 16.0 kg 310 mm 52 mm
11070 B7234-CDLR-T-P4S/ B7234-CDLR-T-P4S 300.00 KN 360.00 KN 170 mm 16.0 kg 310 mm 52 mm
11071 B7234-CDLR-TX-P2/ B7234-CDLR-TX-P2 300.00 KN 360.00 KN 170 mm 16.0 kg 310 mm 52 mm
11072 B7234-EDLR-TX-P2/ B7234-EDLR-TX-P2 300.00 KN 360.00 KN 170 mm 16.0 kg 310 mm 52 mm
11073 B7234-C-P4S-U/ B7234-C-P4S-U 300.00 KN 360.00 KN 170 mm 16.0 kg 310 mm 52 mm
11074 B7234-E-P2-DT/ B7234-E-P2-DT 280.00 KN 345.00 KN 170 mm 16.0 kg 310 mm 52 mm
11075 B7234-E-P2-DB-L/ B7234-E-P2-DB-L 280.00 KN 345.00 KN 170 mm 16.0 kg 310 mm 52 mm
11076 B7234-EDLR-T-P4S/ B7234-EDLR-T-P4S 280.00 KN 345.00 KN 170 mm 16.0 kg 310 mm 52 mm
11077 B7234-E-T-P4S/ B7234-E-T-P4S 280.00 KN 345.00 KN 170 mm 16.0 kg 310 mm 52 mm
11078 B7234-E-P4S-U/ B7234-E-P4S-U 280.00 KN 345.00 KN 170 mm 16.0 kg 310 mm 52 mm
11079 B71836-C-P2-DB/ B71836-C-P2-DB 71.00 KN 93.00 KN 180 mm 1.7 kg 225 mm 22 mm
11080 B71836-C-TPA-P4/ B71836-C-TPA-P4 71.00 KN 93.00 KN 180 mm 1.7 kg 225 mm 22 mm
11081 B71836-CDLR-TX-P2/ B71836-CDLR-TX-P2 71.00 KN 93.00 KN 180 mm 1.7 kg 225 mm 22 mm
11082 B71836-EDLR-TX-P2/ B71836-EDLR-TX-P2 71.00 KN 93.00 KN 180 mm 1.7 kg 225 mm 22 mm
11083 B71836-E-P2-DT/ B71836-E-P2-DT 67.00 KN 86.50 KN 180 mm 1.7 kg 225 mm 22 mm
11084 B71836-E-P2-DB-L/ B71836-E-P2-DB-L 67.00 KN 86.50 KN 180 mm 1.7 kg 225 mm 22 mm
11085 B71836-E-TPA-P4/ B71836-E-TPA-P4 67.00 KN 86.50 KN 180 mm 1.7 kg 225 mm 22 mm
11086 HCB71836-C-TPA-P4/ HCB71836-C-TPA-P4 49.00 KN 65.50 KN 180 mm 1.7 kg 225 mm 22 mm
11087 HCB71836-E-P2-DB/ HCB71836-E-P2-DB 45.50 KN 60.00 KN 180 mm 1.7 kg 225 mm 22 mm
11088 HCB71836-C-P2-DT-L/ HCB71836-C-P2-DT-L 45.50 KN 60.00 KN 180 mm 1.7 kg 225 mm 22 mm
11089 HCB71836-E-TPA-P4/ HCB71836-E-TPA-P4 45.50 KN 60.00 KN 180 mm 1.7 kg 225 mm 22 mm
11090 HCB71836-EDLR-TPA-P4/ HCB71836-EDLR-TPA-P4 45.50 KN 60.00 KN 180 mm 1.7 kg 225 mm 22 mm
11091 B71936-C-P2-DB/ B71936-C-P2-DB 163.00 KN 204.00 KN 180 mm 4.2 kg 250 mm 33 mm
11092 B71936-C-T-P4S/ B71936-C-T-P4S 163.00 KN 204.00 KN 180 mm 4.2 kg 250 mm 33 mm
11093 B71936-CDLR-T-P4S/ B71936-CDLR-T-P4S 163.00 KN 204.00 KN 180 mm 4.2 kg 250 mm 33 mm
11094 B71936-CDLR-TX-P2/ B71936-CDLR-TX-P2 163.00 KN 204.00 KN 180 mm 4.2 kg 250 mm 33 mm
11095 B71936-EDLR-TX-P2/ B71936-EDLR-TX-P2 163.00 KN 204.00 KN 180 mm 4.2 kg 250 mm 33 mm
11096 B71936-C-P4S-U/ B71936-C-P4S-U 163.00 KN 204.00 KN 180 mm 4.2 kg 250 mm 33 mm
11097 B71936-C-P4S-DB/ B71936-C-P4S-DB 163.00 KN 204.00 KN 180 mm 4.2 kg 250 mm 33 mm
11098 B71936-C-P4S-DF/ B71936-C-P4S-DF 163.00 KN 204.00 KN 180 mm 4.2 kg 250 mm 33 mm
11099 B71936-E-P2-DT/ B71936-E-P2-DT 156.00 KN 193.00 KN 180 mm 4.2 kg 250 mm 33 mm
11100 B71936-E-P2-DB-L/ B71936-E-P2-DB-L 156.00 KN 193.00 KN 180 mm 4.2 kg 250 mm 33 mm
