SERIE 70. 70. 718. 719

Das Bild kann vom Produkt abweichen. Weitere Informationen finden Sie in den technischen Daten.

SERIE 70. 70. 718. 719

Die verbesserte Lagerkinematik und höhere Qualität der Laufbahn können die Reibung, Lagertemperaturen und Schmierbedarf verringern.

Standard

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh,DIN / VDEh

Innenringdurchmesser

10mm-280mm

Außenringdurchmesser

20mm-400mm

Gewicht

0.2kg-300kg

Material

GCr15, 52100, 100Cr6, SUJ2, Edelstahl, Deutscher Edelstahl mit hohem Stickstoffgehalt CRONIDUR30, Keramik

Marke

QIBR/OEM/Neutral

Verpackung

QIBR/Standard-Industrieverpackung/OEM

Anwendungen

Werkzeugmaschinenspindel, Zentrifuge, Druckerhöhungspumpe, Ölpumpe, Gebläse, verschiedene Getriebe, Laborgerät

Paarungsmethode

DB, DF, DT, DBD, DBB, SU

SERIE 70. 70. 718. 719

Filter

Nr. Produkt Produktnummer Dynamische Tragzahl Statische Tragzahl Innendurchmesser (d) Masse Außendurchmesser (D) Breite (B)
3101 7019ASN24TYNDBLP4/ 7019ASN24TYNDBLP4 67.0 KN 67.0 KN 95 mm 1.230 kg 145 mm 24 mm
3102 7016ASN24TYNDBLP4/ 7016ASN24TYNDBLP4 53.5 KN 50.5 KN 80 mm 0.864 kg 125 mm 22 mm
3103 7017ASN24TYNDBLP4/ 7017ASN24TYNDBLP4 54.5 KN 53.5 KN 85 mm 0.907 kg 130 mm 22 mm
3104 7021ASN24TYNDBLP4/ 7021ASN24TYNDBLP4 80.0 KN 81.5 KN 105 mm 1.600 kg 160 mm 26 mm
3105 7020ASN24TYNDBLP4/ 7020ASN24TYNDBLP4 68.5 KN 70.5 KN 100 mm 1.280 kg 150 mm 24 mm
3106 7022ASN24TYNDBLP4/ 7022ASN24TYNDBLP4 96.5 KN 95.5 KN 110 mm 1.960 kg 170 mm 28 mm
3107 7026ASN24TYNDBLP4/ 7026ASN24TYNDBLP4 117 KN 125 KN 130 mm 3.260 kg 200 mm 33 mm
3108 7024ASN24TYNDBLP4/ 7024ASN24TYNDBLP4 102 KN 107 KN 120 mm 2.120 kg 180 mm 28 mm
3109 7028ASN24TYNDBLP4/ 7028ASN24TYNDBLP4 120 KN 133 KN 140 mm 3.440 kg 210 mm 33 mm
3110 7034ASN24TYNDBLP4/ 7034ASN24TYNDBLP4 186 KN 214 KN 170 mm 6.940 kg 260 mm 42 mm
3111 7030ASN24TYNDBLP4/ 7030ASN24TYNDBLP4 137 KN 154 KN 150 mm 4.190 kg 225 mm 35 mm
3112 7038ASN24TYNDBLP4/ 7038ASN24TYNDBLP4 224 KN 280 KN 190 mm 11.30 kg 290 mm 46 mm
3113 7200ASN24TYNDBLP4/ 7200ASN24TYNDBLP4 5.05 KN 2.44 KN 10 mm 0.032 kg 30 mm 9 mm
3114 7032ASN24TYNDBLP4/ 7032ASN24TYNDBLP4 155 KN 176 KN 160 mm 5.160 kg 240 mm 38 mm
3115 7036ASN24TYNDBLP4/ 7036ASN24TYNDBLP4 207 KN 252 KN 180 mm 9.270 kg 280 mm 46 mm
3116 7040ASN24TYNDBLP4/ 7040ASN24TYNDBLP4 240 KN 310 KN 200 mm 13.70 kg 310 mm 51 mm
3117 7206ASN24TYNDBLP4/ 7206ASN24TYNDBLP4 21.3 KN 13.6 KN 30 mm 0.197 kg 62 mm 16 mm
3118 7201ASN24TYNDBLP4/ 7201ASN24TYNDBLP4 7.45 KN 3.65 KN 12 mm 0.030 kg 32 mm 10 mm
3119 7205ASN24TYNDBLP4/ 7205ASN24TYNDBLP4 15.4 KN 9.45 KN 25 mm 0.129 kg 52 mm 15 mm
3120 7202ASN24TYNDBLP4/ 7202ASN24TYNDBLP4 8.10 KN 4.25 KN 15 mm 0.045 kg 35 mm 11 mm
3121 7203ASN24TYNDBLP4/ 7203ASN24TYNDBLP4 10.1 KN 5.45 KN 17 mm 0.065 kg 40 mm 12 mm
3122 7204ASN24TYNDBLP4/ 7204ASN24TYNDBLP4 13.6 KN 7.55 KN 20 mm 0.104 kg 47 mm 14 mm
3123 7207ASN24TYNDBLP4/ 7207ASN24TYNDBLP4 28.2 KN 18.5 KN 35 mm 0.284 kg 72 mm 17 mm
3124 7211ASN24TYNDBLP4/ 7211ASN24TYNDBLP4 49.0 KN 37.0 KN 55 mm 0.609 kg 100 mm 21 mm
3125 7209ASN24TYNDBLP4/ 7209ASN24TYNDBLP4 37.5 KN 26.7 KN 45 mm 0.410 kg 85 mm 19 mm
3126 7208ASN24TYNDBLP4/ 7208ASN24TYNDBLP4 33.5 KN 23.3 KN 40 mm 0.370 kg 80 mm 18 mm
3127 7214ASN24TYNDBLP4/ 7214ASN24TYNDBLP4 73.0 KN 59.5 KN 70 mm 1.100 kg 125 mm 24 mm
3128 7213ASN24TYNDBLP4/ 7213ASN24TYNDBLP4 67.5 KN 54.0 KN 65 mm 1.020 kg 120 mm 23 mm
3129 7210ASN24TYNDBLP4/ 7210ASN24TYNDBLP4 39.5 KN 29.3 KN 50 mm 0.462 kg 90 mm 20 mm
3130 7212ASN24TYNDBLP4/ 7212ASN24TYNDBLP4 59.0 KN 45.5 KN 60 mm 0.789 kg 110 mm 22 mm
3131 726ATYNDBLP4/ 726ATYNDBLP4 2.240 KN 0.940 KN 6 mm 7.8 g 19 mm 6 mm
3132 7215ASN24TYNDBLP4/ 7215ASN24TYNDBLP4 76.0 KN 64.5 KN 75 mm 1.200 kg 130 mm 25 mm
3133 7221ASN24TYNDBLP4/ 7221ASN24TYNDBLP4 150 KN 132 KN 105 mm 3.820 kg 190 mm 36 mm
3134 7216ASN24TYNDBLP4/ 7216ASN24TYNDBLP4 85.5 KN 71.5 KN 80 mm 1.450 kg 140 mm 26 mm
3135 7220ASN24TYNDBLP4/ 7220ASN24TYNDBLP4 137 KN 117 KN 100 mm 3.210 kg 180 mm 34 mm
3136 7218ASN24TYNDBLP4/ 7218ASN24TYNDBLP4 113 KN 96.5 KN 90 mm 2.230 kg 160 mm 30 mm
3137 7224ASN24TYNDBLP4/ 7224ASN24TYNDBLP4 183 KN 177 KN 120 mm 5.450 kg 215 mm 40 mm
3138 7217ASN24TYNDBLP4/ 7217ASN24TYNDBLP4 98.5 KN 83.5 KN 85 mm 1.800 kg 150 mm 28 mm
3139 7219ASN24TYNDBLP4/ 7219ASN24TYNDBLP4 122 KN 103 KN 95 mm 2.670 kg 170 mm 32 mm
3140 7222ASN24TYNDBLP4/ 7222ASN24TYNDBLP4 162 KN 148 KN 110 mm 4.490 kg 200 mm 38 mm
3141 7228ASN24TYNDBLP4/ 7228ASN24TYNDBLP4 218 KN 234 KN 140 mm 7.970 kg 250 mm 42 mm
3142 7226ASN24TYNDBLP4/ 7226ASN24TYNDBLP4 189 KN 193 KN 130 mm 6.280 kg 230 mm 40 mm
3143 7230ASN24TYNDBLP4/ 7230ASN24TYNDBLP4 248 KN 280 KN 150 mm 11.200 kg 270 mm 45 mm
3144 725ATYNDBLP4/ 725ATYNDBLP4 1.610 KN 0.620 KN 5 mm 4.5 g 16 mm 5 mm
3145 H7001 H7001 C/HQ1 3.8 KN 1.7 KN 12 mm 0.02 kg 28 mm 8 mm
3146 H7000 H7000 C/HQ1 3.4 KN 1.5 KN 10 mm 0.02 kg 26 mm 8 mm
3147 H7000 H7000 C/HQ1 5.30 KN 2.49 KN 10 mm 0.019 kg 26 mm 8 mm
3148 H7002 H7002 C/HQ1 4.4 KN 2.2 KN 15 mm 0.030 kg 32 mm 9 mm
3149 7930A5SN24TRDBLP4/ 7930A5SN24TRDBLP4 96.5 KN 115 KN 150 mm 2.970 kg 210 mm 28 mm
3150 7932A5SN24TRDBLP4/ 7932A5SN24TRDBLP4 100 KN 125 KN 160 mm 3.120 kg 220 mm 28 mm
3151 7928A5SN24TRDBLP4/ 7928A5SN24TRDBLP4 75.0 KN 90.0 KN 140 mm 1.630 kg 190 mm 24 mm
3152 7934A5SN24TRDBLP4/ 7934A5SN24TRDBLP4 106 KN 140 KN 170 mm 3.360 kg 230 mm 28 mm
3153 7936A5SN24TRDBLP4/ 7936A5SN24TRDBLP4 137 KN 174 KN 180 mm 4.940 kg 250 mm 33 mm
3154 7938A5SN24TRDBLP4/ 7938A5SN24TRDBLP4 139 KN 182 KN 190 mm 5.120 kg 260 mm 33 mm
3155 7940A5SN24TRDBLP4/ 7940A5SN24TRDBLP4 178 KN 231 KN 200 mm 6.920 kg 280 mm 38 mm
3156 7948A5SN24TRDBLP4/ 7948A5SN24TRDBLP4 189 KN 270 KN 240 mm 7.224 kg 320 mm 38 mm
3157 7944A5SN24TRDBLP4/ 7944A5SN24TRDBLP4 179 KN 242 KN 220 mm 6.665 kg 300 mm 38 mm
3158 7952A5SN24TRDBLP4/ 7952A5SN24TRDBLP4 241 KN 345 KN 260 mm 11.936 kg 360 mm 46 mm
3159 7001A5SN24TRDBLP4/ 7001A5SN24TRDBLP4 5.60 KN 2.79 KN 12 mm 0.021 kg 28 mm 8 mm
3160 706ACD/HCP4A 706ACD/HCP4A 1.95 KN 0.75 KN 6 mm 0.005 kg 17 mm 6 mm
3161 7956A5SN24TRDBLP4/ 7956A5SN24TRDBLP4 256 KN 390 KN 280 mm 12.853 kg 380 mm 46 mm
3162 HC706-C-T-P2/ HC706-C-T-P2 1.08 KN 0.48 KN 6 mm 0.010 kg 17 mm 6 mm
3163 7007ACD/HCP4A 7007ACD/HCP4A 14.8 KN 9 KN 35 mm 0.130 kg 62 mm 14 mm
3164 HS708-E-P2-L/ HS708-E-P2-L 1.80 KN 0.95 KN 8 mm 0.010 kg 22 mm 7 mm
3165 7000A5SN24TRDBLP4/ 7000A5SN24TRDBLP4 5.15 KN 2.41 KN 10 mm 0.019 kg 26 mm 8 mm
3166 7005A5SN24TRDBLP4/ 7005A5SN24TRDBLP4 11.1 KN 7.10 KN 25 mm 0.077 kg 47 mm 12 mm
3167 7009A5SN24TRDBLP4/ 7009A5SN24TRDBLP4 23.1 KN 18.3 KN 45 mm 0.250 kg 75 mm 16 mm
3168 7002A5SN24TRDBLP4/ 7002A5SN24TRDBLP4 5.95 KN 3.25 KN 15 mm 0.030 kg 32 mm 9 mm
3169 7003A5SN24TRDBLP4/ 7003A5SN24TRDBLP4 6.30 KN 3.65 KN 17 mm 0.040 kg 35 mm 10 mm
3170 7004A5SN24TRDBLP4/ 7004A5SN24TRDBLP4 10.6 KN 6.25 KN 20 mm 0.067 kg 42 mm 12 mm
3171 7006A5SN24TRDBLP4/ 7006A5SN24TRDBLP4 14.4 KN 9.80 KN 30 mm 0.114 kg 55 mm 13 mm
3172 7007A5SN24TRDBLP4/ 7007A5SN24TRDBLP4 18.2 KN 13.0 KN 35 mm 0.151 kg 62 mm 14 mm
3173 7008A5SN24TRDBLP4/ 7008A5SN24TRDBLP4 19.5 KN 15.1 KN 40 mm 0.188 kg 68 mm 15 mm
3174 HS709-E-P2-L/ HS709-E-P2-L 2.50 KN 1.37 KN 9 mm 0.020 kg 24 mm 7 mm
3175 7900A5M/ 7900A5M 2.88 KN 1.45 KN 10 mm 0.009 kg 22 mm 6 mm
3176 7011A5SN24TRDBLP4/ 7011A5SN24TRDBLP4 32.5 KN 27.2 KN 55 mm 0.383 kg 90 mm 18 mm
3177 7010A5SN24TRDBLP4/ 7010A5SN24TRDBLP4 24.6 KN 20.8 KN 50 mm 0.270 kg 80 mm 16 mm
3178 7207ACD/HCP4A 7207ACD/HCP4A 30.7 KN 20.8 KN 35 mm 0.240 kg 72 mm 17 mm
3179 7014A5SN24TRDBLP4/ 7014A5SN24TRDBLP4 44.5 KN 41.0 KN 70 mm 0.625 kg 110 mm 20 mm
3180 7013A5SN24TRDBLP4/ 7013A5SN24TRDBLP4 35.0 KN 32.5 KN 65 mm 0.455 kg 100 mm 18 mm
3181 7012A5SN24TRDBLP4/ 7012A5SN24TRDBLP4 33.0 KN 29.1 KN 60 mm 0.408 kg 95 mm 18 mm
3182 7019A5SN24TRDBLP4/ 7019A5SN24TRDBLP4 69.5 KN 69.5 KN 95 mm 1.410 kg 145 mm 24 mm
3183 7017A5SN24TRDBLP4/ 7017A5SN24TRDBLP4 57.0 KN 55.5 KN 85 mm 0.904 kg 130 mm 22 mm
3184 7018A5SN24TRDBLP4/ 7018A5SN24TRDBLP4 68.0 KN 65.5 KN 90 mm 1.170 kg 140 mm 24 mm
3185 HS706-E-P2-L/ HS706-E-P2-L 1.50 KN 0.66 KN 6 mm 0.010 kg 17 mm 6 mm
3186 7015A5SN24TRDBLP4/ 7015A5SN24TRDBLP4 45.5 KN 43.5 KN 75 mm 0.652 kg 115 mm 20 mm
3187 7016A5SN24TRDBLP4/ 7016A5SN24TRDBLP4 55.5 KN 52.5 KN 80 mm 0.880 kg 125 mm 22 mm
3188 7220CLP2/ 7220CLP2 149 KN 127 KN 100 mm 3.180 kg 180 mm 34 mm
3189 7021A5SN24TRDBLP4/ 7021A5SN24TRDBLP4 83.5 KN 85.0 KN 105 mm 1.820 kg 160 mm 26 mm
3190 71908ACD/HCP4A 71908ACD/HCP4A 11.7 KN 8 KN 40 mm 0.10 kg 62 mm 12 mm
3191 7222CLP2/ 7222CLP2 176 KN 160 KN 110 mm 4.450 kg 200 mm 38 mm
3192 7022A5SN24TRDBLP4/ 7022A5SN24TRDBLP4 100 KN 99.0 KN 110 mm 2.260 kg 170 mm 28 mm
3193 7224CLP2/ 7224CLP2 199 KN 192 KN 120 mm 5.420 kg 215 mm 40 mm
3194 7024A5SN24TRDBLP4/ 7024A5SN24TRDBLP4 106 KN 111 KN 120 mm 2.430 kg 180 mm 28 mm
3195 7028A5SN24TRDBLP4/ 7028A5SN24TRDBLP4 125 KN 138 KN 140 mm 3.870 kg 210 mm 33 mm
3196 7008ACD/HCP4A 7008ACD/HCP4A 15.9 KN 10.4 KN 40 mm 0.170 kg 68 mm 15 mm
3197 7026A5SN24TRDBLP4/ 7026A5SN24TRDBLP4 122 KN 130 KN 130 mm 3.660 kg 200 mm 33 mm
3198 7016ACD/HCP4A 7016ACD/HCP4A 62.4 KN 58.5 KN 80 mm 0.71 kg 125 mm 22 mm
3199 7208ACD/HCP4A 7208ACD/HCP4A 31.9 KN 22.8 KN 40 mm 0.330 kg 80 mm 18 mm
3200 7216CTYN/ 7216CTYN 93.0 KN 77.5 KN 80 mm 1.430 kg 140 mm 26 mm
