Zweireihige Kegelrollenlager – Typ TNA

Zweireihige Kegelrollenlager vom Typ TNA (Tapered Double Inner) sind fortschrittliche Lager, die für hohe Tragfähigkeit und effizienten Betrieb in verschiedenen industriellen Anwendungen ausgelegt sind.

Komponenten: TNA-Lager bestehen aus zwei Reihen von Kegelrollen, die zwischen einem doppelten Außenring (Cup) und zwei Innenringen (Cones) angeordnet sind. Diese Anordnung ermöglicht eine effektive Lastverteilung und verbessert die Gesamtleistung des Lagers.

Trennbare Ausführung: Die Innenringe und der Außenring lassen sich leicht trennen, was die Installation und Wartung vereinfacht. Diese Konstruktion ermöglicht den einfachen Austausch von Komponenten, ohne dass das gesamte Lager ausgetauscht werden muss.

Käfigausführung: Diese Lager verfügen in der Regel über einen Käfig aus hochfestem Pressstahl, der die Rollen gleichmäßig hält und verteilt, was für die Aufrechterhaltung der Leistung bei hohen Lasten und Geschwindigkeiten von entscheidender Bedeutung ist.

Standard

GB,ASTM/AISI,ГОСТ,BS,JIS,NF,DIN / VDEh,DIN / VDEh

Material

GCr15

Innenringdurchmesser

0.75-16 inch

Außenringdurchmesser

1.8504-23 inch

Marke

QIBR/OEM/Neutral

Verpackung

QIBR/Standard-Industrieverpackung/OEM

Anwendungen

Luft- und Raumfahrt, Industriemaschinen, Eisenbahn, Automobil

Zweireihige Kegelrollenlager – Typ TNA

Filter

Nr. Produkt Produktnummer Lagerbeite (T) Bohrung Außendurchmesser des Außenrings (D) Breite doppeltes Außenrings (C) Dynamische radiale Belastung Gewicht
1 NA05075 NA05075 - 05185D 1.25 inch 0.75 inch 1.8504 inch 0.9926 inch 10500 lbf 0.51 lbs
2 NA17098 NA17098 - 17245D 1.5625 inch 0.9835 inch 2.4409 inch 1.4275 inch 16900 lbf 1.36 lbs
3 NA41125 NA41125 - 41294D 2.1876 inch 1.125 inch 2.9375 inch 1.625 inch 27300 lbf 2.45 lbs
4 NA26118 NA26118 - 26284D 1.6835 inch 1.1806 inch 2.8336 inch 1.4375 inch 23000 lbf 1.87 lbs
5 NA08125 NA08125 - 08231D 1.2812 inch 1.25 inch 2.3125 inch 0.9688 inch 12400 lbf 0.79 lbs
6 NA43131 NA43131 - 43319D 2.1875 inch 1.3125 inch 3.1875 inch 1.5625 inch 30400 lbf 2.82 lbs
7 NA14138 NA14138 - 14276D 1.8126 inch 1.375 inch 2.717 inch 1.5 inch 21400 lbf 1.56 lbs
8 NA28138 NA28138 - 28318D 1.8126 inch 1.377 inch 3.151 inch 1.375 inch 24800 lbf 2.32 lbs
9 NA44143 NA44143 - 44363D 2.1875 inch 1 7/16 inch 3.625 inch 1.5625 inch 32900 lbf 3.85 lbs
10 NA13687 NA13687 - 13621D 1.8124 inch 1 1/2 inch 2.717 inch 1.5 inch 22200 lbf 1.48 lbs
11 NA44156 NA44156 - 44348D 2.1875 inch 1.5625 inch 3.4843 inch 1.5625 inch 32900 lbf 3.26 lbs
12 NA44156 NA44156 - 44363D 2.1875 inch 1.5625 inch 3.625 inch 1.5625 inch 32900 lbf 3.65 lbs
13 NA357 NA357 - 353D 2 inch 1.5748 inch 3.548 inch 1.75 inch 32000 lbf 3.39 lbs
14 NA44163 NA44163 - 44363D 2.1875 inch 1 5/8 inch 3.625 inch 1.5625 inch 39100 lbf 3.57 lbs
15 NA22171 NA22171 - 22325D 1.75 inch 1.7188 inch 3.25 inch 1.375 inch 30300 lbf 2.21 lbs
16 NA18685 NA18685 - 18620D 1.6249 inch 1 3/4 inch 3.125 inch 1.3125 inch 20400 lbf 1.75 lbs
17 NA438 NA438 - 432D 2.4376 inch 1 3/4 inch 3.75 inch 2 inch 49700 lbf 4.41 lbs
18 NA53176 NA53176 - 53376D 2.5626 inch 1 3/4 inch 3.75 inch 1.75 inch 39200 lbf 4.21 lbs
19 NA53176 NA53176 - 53390D 2.5626 inch 1 3/4 inch 3.875 inch 1.75 inch 39200 lbf 4.62 lbs
20 NA366 NA366 - 363D 1.9689 inch 1.9685 inch 3.5433 inch 1.6563 inch 39900 lbf 2.61 lbs
21 NA3780 NA3780 - 3729D 2.5625 inch 2 inch 3.6718 inch 2.0625 inch 47800 lbf 4.02 lbs
22 NA455 NA455 - 452D 2.5626 inch 2 inch 4.25 inch 2.125 inch 53100 lbf 6.1 lbs
23 NA55200 NA55200 - 55444D 2.5625 inch 2 inch 4.4375 inch 1.8125 inch 41600 lbf 6.25 lbs
24 NA539 NA539 - 533D 3.125 inch 2.125 inch 4.375 inch 2.5 inch 67400 lbf 7.39 lbs
25 NA66212 NA66212 - 66462D 2.875 inch 2.125 inch 4.625 inch 2.125 inch 58300 lbf 7.82 lbs
26 NA72212 NA72212 - 72488D 3.0625 inch 2.125 inch 4.875 inch 2.1875 inch 64600 lbf 9 lbs
27 NA385 NA385 - 384CD 2.0625 inch 2.1654 inch 3.937 inch 1.6875 inch 42200 lbf 3.45 lbs
28 NA397 NA397 - 394D 2.0625 inch 2.3622 inch 4.3307 inch 1.8125 inch 38700 lbf 4.51 lbs
29 NA476 NA476 - 472D 2.5626 inch 2.3622 inch 4.7244 inch 2.125 inch 56100 lbf 7.59 lbs
30 NA558 NA558 - 552D 3.125 inch 2.375 inch 4.875 inch 2.5 inch 74700 lbf 9.5 lbs
31 NA78250 NA78250 - 78549D 3.0625 inch 2 1/2 inch 5.5 inch 2.0395 inch 79300 lbf 11.28 lbs
32 NA569 NA569 - 563D 3.1875 inch 2.625 inch 5 inch 2.5625 inch 76900 lbf 9.64 lbs
33 NA482 NA482 - 472D 2.5626 inch 2 3/4 inch 4.7244 inch 2.125 inch 56100 lbf 6.46 lbs
34 NA643 NA643 - 632D 3.75 inch 2 3/4 inch 5.375 inch 3 inch 91200 lbf 12.92 lbs
35 NA484 NA484 - 472D 2.5626 inch 2.7559 inch 4.7244 inch 2.125 inch 56100 lbf 6.44 lbs
36 NA567 NA567 - 563D 3.1875 inch 2.875 inch 5 inch 2.5625 inch 76900 lbf 8.52 lbs
37 NA495A NA495A - 493D 2.75 inch 3 inch 5.375 inch 2.125 inch 60500 lbf 9.12 lbs
38 NA659 NA659 - 654D 3.75 inch 3 inch 6 inch 3 inch 96700 lbf 16.77 lbs
39 NA9378 NA9378 - 9320D 4.3125 inch 3 inch 7 inch 2.9375 inch 142000 lbf 27.2 lbs
40 NA580 NA580 - 572D 3.25 inch 3 1/4 inch 5.5115 inch 2.625 inch 80900 lbf 10.56 lbs
41 NA749 NA749 - 742D 4 inch 3 1/4 inch 6.125 inch 3.375 inch 147000 lbf 18.01 lbs
42 NA842 NA842 - 834D 4.9375 inch 3 1/4 inch 6.75 inch 3.9375 inch 160000 lbf 28.88 lbs
43 NA593 NA593 - 592D 3.25 inch 3 1/2 inch 6 inch 2.5 inch 84600 lbf 12.93 lbs
44 NA759 NA759 - 752D 4.125 inch 3 1/2 inch 6.375 inch 3.375 inch 128000 lbf 19.28 lbs
45 NA98350 NA98350 - 98789D 4.5625 inch 3 1/2 inch 7.875 inch 3.1581 inch 159000 lbf 36.5 lbs
46 NA52375 NA52375 - 52637D 3.2499 inch 3 3/4 inch 6.375 inch 2.4375 inch 87500 lbf 14.41 lbs
47 NA776 NA776 - 774CD 4.125 inch 3 3/4 inch 7.125 inch 3.375 inch 135000 lbf 25.21 lbs
48 NA691A NA691A - 672D 3.625 inch 3.937 inch 6.625 inch 2.75 inch 104000 lbf 16.78 lbs
49 NA691 NA691 - 672D 3.625 inch 4 inch 6.625 inch 2.75 inch 104000 lbf 16.69 lbs
50 NA780 NA780 - 773D 4.125 inch 4 inch 7.0866 inch 3.375 inch 135000 lbf 23.56 lbs
51 NA780 NA780 - 774CD 4.125 inch 4 inch 7.125 inch 3.375 inch 135000 lbf 23.43 lbs
52 NA861 NA861 - 854D 5 inch 4 inch 7.5 inch 4 inch 179000 lbf 33.03 lbs
53 HH221449NA HH221449NA - HH221410D 5 inch 4 inch 7.5 inch 4.125 inch 209000 lbf 32.64 lbs
54 NA782 NA782 - 774CD 4.125 inch 4.125 inch 7.125 inch 3.375 inch 135000 lbf 22.5 lbs
55 NA71450 NA71450 - 71751D 4.1875 inch 4.5 inch 7.5 inch 3.1875 inch 142000 lbf 24.43 lbs
56 NA97450 NA97450 - 97901D 4.5625 inch 4.5 inch 9 inch 3.3125 inch 147000 lbf 43.7 lbs
57 HM926740NA HM926740NA - HM926710CD 4.5625 inch 4.5 inch 9 inch 3.3125 inch 194000 lbf 45.41 lbs
58 NA48291 NA48291 - 48220D 3.375 inch 5 inch 7.1875 inch 2.875 inch 105000 lbf 15.71 lbs
59 NA48385 NA48385 - 48320D 3.375 inch 5.25 inch 7.5 inch 2.875 inch 111000 lbf 16.45 lbs
60 NA48686 NA48686 -48620D 3.6876 inch 5.625 inch 7.875 inch 2.875 inch 112000 lbf 18.56 lbs
61 NA82576 NA82576 - 82932D 5.1875 inch 5.75 inch 9.3125 inch 4.1875 inch 202000 lbf 45.41 lbs
62 HM231140NA HM231140NA - HM231116D 5.1875 inch 5.75 inch 9.5 inch 4.1875 inch 234000 lbf 48.5 lbs
63 NA82587 NA82587 - 82932D 5.1875 inch 5.875 inch 9.3125 inch 4.1875 inch 202000 lbf 43.73 lbs
64 HM231149NA HM231149NA - HM231116D 5.1875 inch 5.875 inch 9.5 inch 4.1875 inch 234000 lbf 46.82 lbs
65 M231647- M231647- M231616XD 4.252 inch 5.9436 inch 9.0501 inch 4.5669 inch 134000 lbf 35.57 lbs
66 NA99600 NA99600 - 99102CD 5.625 inch 6 inch 10 inch 4.375 inch 258000 lbf 58.51 lbs
67 NA94650 NA94650 - 94118D 5.625 inch 6.5 inch 11.75 inch 4.375 inch 258000 lbf 91.93 lbs
68 NA87700 NA87700 - 87112D 4.25 inch 7 inch 11.125 inch 3.125 inch 168000 lbf 50.8 lbs
69 NA94700 NA94700 - 94117D 5.625 inch 7 inch 11.75 inch 5.5 inch 258000 lbf 88.35 lbs
70 NA94700 NA94700 - 94118D 5.625 inch 7 inch 11.75 inch 4.375 inch 258000 lbf 83.46 lbs
71 NA537075 NA537075 - 537103D 2.625 inch 7.5 inch 10.25 inch 2 inch 92100 lbf 21 lbs
72 NA132083 NA132083 - 132126D 4.75 inch 8 inch 12.5 inch 3.5 inch 207000 lbf 73.89 lbs
73 HM252343NA HM252343NA - HM252311D 6.8125 inch 10 inch 16.625 inch 5.0625 inch 587000 lbf 188.93 lbs
74 HM252344NA HM252344NA - HM252315CD 6.8125 inch 10 inch 16.997 inch 5.0625 inch 605000 lbf 212.55 lbs
75 HM252343NA HM252343NA - HM252315CD 6.8125 inch 10 inch 16.997 inch 5.0625 inch 587000 lbf 202.94 lbs
76 HM252349NA HM252349NA - HM252311D 6.8125 inch 10.25 inch 16.625 inch 5.0625 inch 605000 lbf 190.86 lbs
77 HM252348NA HM252348NA - HM252311D 6.8125 inch 10.25 inch 16.625 inch 5.0625 inch 587000 lbf 181.24 lbs
78 HM252349NA- HM252349NA- HM252315CD 6.8125 inch 10.25 inch 16.997 inch 5.0625 inch 605000 lbf 204.87 lbs
79 HM252348NA- HM252348NA- HM252315CD 6.8125 inch
